AP410C hardware components

AP410C hardware components
Figure 1: AP410C access point hardware components
Table 4: Hardware component description
Callout
1
2
3
4
5
6
7

Micro USB console port information

Use the console port to make a serial connection between your management system and the access
point.
Note
When you connect to the device using the micro USB Console port, the management station
from which you connect to the device must have a VT100 emulation program, such as Tera
Term Pro© (a free terminal emulator) or Hilgraeve HyperTerminal® (provided with Windows®
operating systems from XP forward).
10 ExtremeWireless™ AP410C Access Point
AP410C Access Point Overview
Description
Eth0 PoE+
Eth1
USB port
Console port
Reset button
Security slot
Kensington lock
