  • Page 1 Eaton ® ® 9155 UPS 8–15 kVA User’s Guide p/n: 164201553 Revision H0...
  • Page 2 National Fire Protection Association, Inc. ERIFLEX and FLEXIBAR are registered trademark of Erico International Corporation. All other trademarks are property of their respective companies. ©Copyright 2004-2019 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.

  • Page 3: Table Of Contents

    4.3.4.1 MBM/PDM Setup ........................36 4.3.4.2 Wiring the MBM/PDM ......................... 38 4.3.5 Bypass Power Module Installation......................42 4.4 Stabilizing the Cabinet ..........................43 4.5 Internal Battery Tray Wiring Connections ....................... 45 Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 4 1 1 1 1 W W a a r r r r a a n n t t y y ............................................................8 8 9 9 Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 5 L L i i s s t t o o f f F F i i g g u u r r e e s s Figure 1. The Eaton 9155 UPS and EBM (2-High Cabinets Shown) ................ 1 Figure 2.
  • Page 6 Figure 50. External Control Terminal Connections ..................... 64 Figure 51. Eaton 9155 Control Panel....................... 67 Figure 52. Maintenance Bypass Switch......................74 Figure 53. Typical Hardwired Installation with UPS-Mounted Bypass Switch ............75 Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 7 Environmental and Safety Specifications .................... 84 Table 16. Technical Specifications ........................84 Table 17. Model Specifications ........................85 Table 18. Battery Specifications........................87 Table 19. Battery Runtimes (in Minutes) at Full Load ..................87 Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 8: List Of Tables

    List of Tables viii Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 9: Figure 1. The Eaton 9155 Ups And Ebm (2-High Cabinets Shown)

    With the Eaton 9155, you can safely eliminate the effects of electrical line disturbances and guard the integrity of your systems and equipment.

  • Page 10: Bypass Power Module

    1 1 . . 1 1 . . 3 3 B B y y p p a a s s s s P P o o w w e e r r M M o o d d u u l l e e The Eaton Bypass Power Module (BPM) is designed to be a maintenance bypass switch that also contains flexible output power distribution and mounting options.
  • Page 11 U U s s i i n n g g T T h h i i s s M M a a n n u u a a l l This manual describes how to install and operate the Eaton 9155 UPS. Read and understand the procedures described in this manual to ensure trouble-free installation and operation.

  • Page 12: For More Information

    F F o o r r M M o o r r e e I I n n f f o o r r m m a a t t i i o o n n Refer to the Eaton 9155 Parallel UPS 8-15 kVA User’s Guide for the following additional information: •...
  • Page 13 E E q q u u i i p p m m e e n n t t R R e e g g i i s s t t r r a a t t i i o o n n Please visit www.eaton.com/pq/register to register your new Eaton UPS / Eaton UPS Accessory. Model Number: Serial Number:...
  • Page 14 Introduction Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 15 Keep unauthorized personnel away from batteries. • Proper disposal of batteries is required. Refer to your local codes for disposal requirements. • Never dispose of batteries in a fire. Batteries may explode when exposed to flame. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 16 Une mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements en vigueur dans votre localité. • Ne jamais jeter les batteries au feu. L'exposition aux flammes risque de les faire exploser. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 17 Es necesario desechar las baterías de un modo adecuado. Consulte las normas locales para conocer los requisitos pertinentes. • Nunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a la llama. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 18: Safety Warnings

    Safety Warnings Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 19 1.6 Getting Help). • The environmental requirements specified below are for the air at the intake ports of the 9155 UPS, and are the maximum, not to exceed, ratings. – There shall be at least a 1.8°F (1.0°C) difference between the dry bulb temperature and the wet bulb temperature, at all times, to maintain a non-condensing environment.

  • Page 20: Table 1. Air Conditioning Or Ventilation Requirements During Full Load Operation

    When planning the installation, consider the UPS weight for floor loading. The strength of the installation surface must be adequate for point and distributed loadings. The approximate weights are shown in the following table. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 21: Maintenance Bypass Module (Mbm)

    From Front of Cabinet 36” (91.4 cm) working space From Back of Cabinet 6” (15.2 cm) without an MBM/PDM installed; with an MBM/ PDM installed, clearance is determined by the customer- supplied mating Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 22: Figure 2. Ups Cabinet Dimensions (2-High Front And Right Side Views)

    UPS Installation Plan and Unpacking Figure 2. UPS Cabinet Dimensions (2-High Front and Right Side Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 23: Figure 3. Extended Battery Module Dimensions (2-High Front And Right Side Views)

    UPS Installation Plan and Unpacking Figure 3. Extended Battery Module Dimensions (2-High Front and Right Side Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 24: Figure 4. Ups Cabinet Dimensions (3-High Front And Right Side Views)

    UPS Installation Plan and Unpacking Figure 4. UPS Cabinet Dimensions (3-High Front and Right Side Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 25: Figure 5. Extended Battery Module Dimensions (3-High Front And Right Side Views)

    UPS Installation Plan and Unpacking Figure 5. Extended Battery Module Dimensions (3-High Front and Right Side Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 26: Figure 6. Ups Cabinet Dimensions (2 Or 3-High Top And Bottom Views)

    UPS Installation Plan and Unpacking Figure 6. UPS Cabinet Dimensions (2 or 3-High Top and Bottom Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 27: Figure 7. Extended Battery Module Dimensions (2 Or 3-High Top And Bottom Views)

    UPS Installation Plan and Unpacking Figure 7. Extended Battery Module Dimensions (2 or 3-High Top and Bottom Views) Dimensions are in millimeters [inches] Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 28: Figure 8. 2-High Ups Cabinet Center Of Gravity

    Dimensions are in millimeters [inches] Dimensions mm [in] Figure Weight Weight and Center of Gravity kg [lb] Eaton 9155 8-15 kVA UPS 2- 81 [3.2] 452 [17.8] 406 [16.0] 169 [373] High Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 29: Figure 9. 2-High Ebm Cabinet Center Of Gravity

    Dimensions are in millimeters [inches] Dimensions mm [in] Figure Weight Weight and Center of Gravity kg [lb] Eaton 9155 Extended Battery 81 [3.2] 452 [17.8] 406 [16.0] 218 [480] Module 2-High Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 30: Figure 10. 3-High Ups Cabinet Center Of Gravity

    Dimensions are in millimeters [inches] Dimensions mm [in] Figure Weight Weight and Center of Gravity kg [lb] Eaton 9155 8–15 kVA UPS 3- 81 [3.2] 452 [17.8] 610 [24.0] 276 [609] High Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 31: Figure 11. 3-High Ebm Cabinet Center Of Gravity

    U U P P S S S S y y s s t t e e m m P P o o w w e e r r W W i i r r i i n n g g P P r r e e p p a a r r a a t t i i o o n n Read and understand the following notes while planning and performing the installation: Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 32: Table 4. Ups Terminal Block (Tb1) Wiring

    Input neutral must be wired for proper operation. Failure to connect an input neutral will void the warranty. If the optional input transformer is installed, an input neutral is not required. • The Eaton 9155 UPS is a single-feed UPS only. Table 4. UPS Terminal Block (TB1) Wiring Conduit...

  • Page 33: Table 5. Input Isolation Transformer Terminal Block Wiring

    * Use only 75°C-rated copper wire. Minimum wire size is based on 120/208 full load ratings applied to NEC Code Table 310-16. Code may require a larger AWG size than shown in this table because of temperature, number of conductors in the conduit, or long service runs. Follow local requirements. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 34 Carefully inspect the outer packaging for evidence of damage during transit. CAUTION Do not install a damaged cabinet. Report any damage to the carrier and contact an Eaton service representative immediately. NOTE Check the battery recharge date on the packaging label. If the date has expired and the batteries were never recharged, do not use the UPS.
  • Page 35 To remove the UPS or EBM from the shipping pallet: Remove the two M10 bolts securing the stabilizing bracket to the pallet (see Figure 12). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 36: Figure 12. Removing The Stabilizing Bracket Bolts

    Hold the back of the cabinet so that the bolts can be removed easily without the cabinet rolling backward. Remove the two M10 bolts securing the front shipping bracket and remove the bracket (see Figure 13). If needed, adjust the leveling feet to release the bracket. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 37: Figure 13. Removing The Brackets And Shipping Pad

    Slowly roll the cabinet toward the rear of the pallet. Once the pallet tilts, continue rolling the cabinet down the pallet until the cabinet touches the floor (see Figure 14). If needed, adjust the leveling feet so that the cabinet will roll. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 38: Figure 14. Unloading The Cabinet

    4 4 . . 3 3 . . 1 1 S S e e l l e e c c t t i i n n g g a a n n I I n n s s t t a a l l l l a a t t i i o o n n O O p p t t i i o o n n You are now ready to install the Eaton 9155 UPS. Select one of the following installation options according to your UPS configuration: Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 39: Ups Only Installation

    NOTE To accommodate the feature of easy system expandability, it is recommended that initial installation of the Eaton 9155 UPS contain wiring to support the maximum capacity of the UPS cabinet. Switch off utility power to the distribution point where the UPS will be connected. Be absolutely sure there is no power.

  • Page 40: Stabilizing The Cabinet

    Continue to paragraph 4.4 Stabilizing the Cabinet to complete the UPS installation. NOTE Input neutral must be wired for proper operation. Failure to connect an input neutral will void the warranty. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 41: Figure 17. Ups Terminal Block

    Verify that the electrical connections to the installation site have been properly installed. A wall-mounted, user-supplied, readily-accessible disconnection device must be incorporated in the input wiring. Compare the circuit breaker ratings and wire sizes to the specifications in Table Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 42: Figure 18. Ups With Input Isolation Transformer Rear View

    NOTE To accommodate the feature of easy system expandability, it is recommended that initial installation of the Eaton 9155 UPS contain wiring to support the maximum capacity of the UPS cabinet. Switch off utility power to the distribution point where the UPS will be connected. Be absolutely sure there is no power.

  • Page 43: Figure 19. Input Isolation Transformer Hardwiring

    4 4 . . 3 3 . . 4 4 U U P P S S - - M M o o u u n n t t e e d d B B y y p p a a s s s s S S w w i i t t c c h h I I n n s s t t a a l l l l a a t t i i o o n n This section describes the Maintenance Bypass Module (MBM) and Power Distribution Module (PDM) installation. Both modules have a Make-Before-Break (MBB) maintenance bypass switch. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 44: Figure 20. Ups Rear View (2-High Cabinet Shown)

    Attach the supplied L-bracket to the lower rear (for 2-high) or middle rear (for 3-high) cabinet using three screws (see Figure 21). Repeat for the other side. Remove the UPS wiring access cover and retain. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 45: Figure 21. Attaching The L-Brackets

    Secure the sides of the module to the L-brackets using six screws (see Figure 23). Secure the top of the module to the top cabinet using four of the screws removed in Step Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 46: Figure 23. Securing The Mbm Or Pdm

    NOTE To accommodate the feature of easy system expandability, it is recommended that initial installation of the Eaton 9155 UPS contain wiring to support the maximum capacity of the UPS cabinet. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 47: Figure 24. Ups With Mbm Rear View

    Punch two holes in the MBM/PDM conduit landing plate for the input and output conduit using a Greenlee punch or similar device. Hardwire the input, output, and ground terminations for the MBM/PDM. Table 6 for specifications and Figure 19 for a detailed view of the MBM/PDM terminal block. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 48: Figure 25. Mbm/Pdm Hardwiring

    Input neutral must be wired for proper operation. Failure to connect an input neutral will void the warranty. However, when wired with the optional isolation transformer, input neutral is supplied by the isolation transformer. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 49: Figure 26. Wiring From Maintenance Bypass Switch To Ups

    Replace the wiring access cover on the UPS and the optional isolation transformer, if applicable. 10. Replace the MBM/PDM wiring access cover and conduit landing plate. 11. Continue to paragraph 4.4 Stabilizing the Cabinet to complete the installation. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 50: Figure 27. Bypass Power Module Dimensions

    4 4 . . 3 3 . . 5 5 B B y y p p a a s s s s P P o o w w e e r r M M o o d d u u l l e e I I n n s s t t a a l l l l a a t t i i o o n n For complete details on the installation process, and operation of the Eaton Bypass Power Module, refer to the Eaton Bypass Power Module (BPM) User’s Guide, listed in paragraph...

  • Page 51: Figure 28. Lowering The Leveling Feet

    S S t t a a b b i i l l i i z z i i n n g g t t h h e e C C a a b b i i n n e e t t NOTE 1 For seismic installations, you MUST order and install an Eaton 9155 UPS seismic kit; do not use the following instructions.

  • Page 52: Figure 29. Stabilizing Bracket With One Cabinet

    UPS System Installation Figure 29. Stabilizing Bracket with One Cabinet M4 Screws Figure 30. Stabilizing Bracket with Two Cabinets M4 Screws Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 53: Figure 31. Stabilizing Bracket With Three Cabinets

    WARNING Only qualified service personnel (such as a licensed electrician) should perform the UPS installation. Initial startup must be performed by an authorized Eaton Customer Service Engineer. Risk of electrical shock. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 54: Figure 32. Removing The Front Covers

    The battery cover panel is made up of two parts joined together with four screws. Remove both parts of the panel at the same time by removing the 10 M4 screws on the edges of the panel and M4 screw in the middle of the panel (see Figure 33). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 55: Figure 33. Battery Panel (Dead Front)

    2-High Cabinet Shown Battery Panel (Dead Front) Connect the UPS battery wiring to the Battery tray wiring, red connector to red connector, black connector to black connector (see Figure 34 Figure 35). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 56: Figure 34. Internal Battery Tray Wiring Connections

    Figure 34. Internal Battery Tray Wiring Connections Black Connector Connector Black Connector Connector Cabinet White Wire Wiring Harness Black Wire Wire Black Black White Wire Black Black Battery Tray Battery Tray Wiring Wiring Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 57: Extended Battery Module Installation

    Position the EBM adjacent to the next cabinet. Verify that all battery circuit breakers are in the OFF position (see Figure 36). Remove the two ground straps from the EBM rear panel. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 58: Communication Options

    UPS system. NOTE After UPS startup, ensure maximum battery runtime by configuring the UPS for the correct number of EBMs (see paragraph 7.5 Configuring the UPS for EBMs). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 59: Figure 37. Front Ground Strap Installation (2-High Cabinets Shown)

    UPS System Installation Figure 37. Front Ground Strap Installation (2-High Cabinets Shown) Front Ground Strap Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 60: Ups System Installation

    UPS System Installation Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 61: Figure 38. Ups Only Wiring Diagram

    C C h h a a p p t t e e r r 5 5 U U P P S S W W i i r r i i n n g g D D i i a a g g r r a a m m s s a a n n d d S S c c h h e e m m a a t t i i c c s s Figure 38. UPS Only Wiring Diagram Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 62: Figure 39. Ups With Input Isolation Transformer Wiring Diagram

    UPS Wiring Diagrams and Schematics Figure 39. UPS with Input Isolation Transformer Wiring Diagram Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 63: Figure 40. Ups With Input Isolation Transformer And Mbm/Pdm Wiring Diagram

    UPS Wiring Diagrams and Schematics Figure 40. UPS with Input Isolation Transformer and MBM/PDM Wiring Diagram Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 64: Figure 41. Ups With Mbm Wiring Diagram

    UPS Wiring Diagrams and Schematics Figure 41. UPS with MBM Wiring Diagram Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 65: Figure 42. Ups With Pdm Wiring Diagram

    UPS Wiring Diagrams and Schematics Figure 42. UPS with PDM Wiring Diagram Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 66 UPS Wiring Diagrams and Schematics Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 67: Figure 43. Communication Options And Control Terminals

    Remove the front covers of all cabinets, starting with the top cabinet. Press and release the handle latch at the bottom of each cover and then lift the cover up and off the cabinet (see Figure 44). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 68: Figure 44. Removing The Front Covers

    On the bottom cover (and also the middle cover if 3-high), remove a knockout tab in the top edge of the cover for each cable: With wire cutters, cut either side of the tab and twist down to remove the tab (see Figure 46). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 69: Figure 46. Removing Knockout Tabs

    Hang the top edge of the cover on the cabinet first, then lower the bottom edge and snap into place. Be sure the cables fit in the access holes in the covers. Continue to Chapter 7 UPS Operating Instructions to start up the UPS. Figure 47. Reinstalling the Front Covers Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 70: Figure 48. Communication Port

    C C o o m m m m u u n n i i c c a a t t i i o o n n O O p p t t i i o o n n s s The Eaton 9155 has serial communication capabilities through the DB-9 communication port or through an X- Slot card in one of the available bays.

  • Page 71: Figure 49. Optional X-Slot Cards

    6 6 . . 2 2 . . 2 2 X X - - S S l l o o t t C C a a r r d d s s X-Slot cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The Eaton 9155 has two available communication bays for any X-Slot card, including: •...

  • Page 72: Figure 50. External Control Terminal Connections

    UPS or power information. If there is a power outage and the Eaton 9155 UPS battery power becomes low, power management software can automatically shut down your computer system to protect your data before the UPS shutdown occurs.

  • Page 73: Relay Output Contacts

    NOTE Figure 50 for the polarity and verify these connections if polarity control is required. The default and programmable settings for the signal inputs are shown in Table Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 74: Table 8. Programmable Signal Inputs

    If active, the UPS knows that input is fed from the generator. Bypass is disabled; the automatic battery On Generator test is disabled. External Transformer This option is not used. Overtemperature Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 75: Figure 51. Eaton 9155 Control Panel

    C C h h a a p p t t e e r r 7 7 U U P P S S O O p p e e r r a a t t i i n n g g I I n n s s t t r r u u c c t t i i o o n n s s This chapter contains information on how to use the Eaton 9155, including front panel operation, UPS startup and shutdown, operation of the maintenance bypass switch, and configuring the UPS for Extended Battery Modules (EBMs).

  • Page 76: Display Functions

    As the default or after 15 minutes of inactivity, the LCD displays the selectable startup screen. The default is the Eaton logo and can be changed to the Mimic screen in the User Settings menu. The backlit LCD automatically dims after a long period of inactivity. Press any button to restore the screen.

  • Page 77: Table 10. User Settings

    Enabled/Disabled Enabled Number of Battery Strings 0 through 22 2 strings for UPS-32 models (see paragraph 4 strings for UPS-64 models 7.5 Configuring the UPS for EBMs for more information. ) Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 78 See for details. This service is offered as part of the sales contract for the UPS. Contact an Eaton service representative in advance (a minimum two- week notice is required) to reserve a preferred startup date.

  • Page 79: Normal Mode Startup

    Refer to the Eaton Bypass Power Module (BPM) User’s Guide. Parallel UPS Refer to the Eaton 9155 Parallel UPS (8–15 kVA) User's Guide. configuration 7 7 . . 2 2 . . 1 1 N N o o r r m m a a l l M M o o d d e e S S t t a a r r t t u u p p...
  • Page 80 Go to Bypass Mode option. indicators illuminate, indicating the UPS is operating in Bypass mode. The load is now powered by utility power. To switch to Normal mode from internal Bypass mode: Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 81 The UPS-mounted maintenance bypass switch is part of the optional Maintenance Bypass Module (MBM) or Power Distribution Module (PDM) and is located on the back of the UPS (see Figure 52). Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 82: Figure 52. Maintenance Bypass Switch

    However, because BYPASS also disconnects AC input from the UPS, this is the appropriate position for UPS maintenance or repair. Figure 53 shows a UPS with a separate battery cabinet and a UPS-mounted bypass switch. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 83: Figure 53. Typical Hardwired Installation With Ups-Mounted Bypass Switch

    Th card. Alarm Indicator startup screen. The default is the Eaton logo and can be changed to the Mimic screen in the User Setting uminate. As the default or after 15 minutes of inactivity, the LCD displays the selectable in the User Settings menu.
  • Page 84 As the default or after 15 minutes of inactivity, the LCD displays the selectable startup screen. The default is the Eaton startup screen. The default is the Eaton logo and can be changed to the Mimic screen in the User Settings menu.

  • Page 85: Ups Operating Instructions

    * UPS-32 models contain 2 strings; EBM-64 models contain 4 strings. UPS-64 models contain 4 strings; EBM-96 models contain 6 strings. Press the button to save the setting. Press the button until the Eaton logo appears. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 86 UPS Operating Instructions Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 87 R R e e c c y y c c l l i i n n g g t t h h e e U U s s e e d d B B a a t t t t e e r r y y o o r r U U P P S S Contact your local recycling or hazardous waste center for information on proper disposal of the used battery or UPS. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 88 For more information, contact your local recycling/reuse or hazardous waste center. CAUTION Do not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 89: Typical Alarms And Conditions

    1 beep every second mounted bypass switch, turn the maintenance bypass switch to the LINE position. Otherwise, shut down the UPS. Clear vents and remove any heat sources. Allow the UPS to cool. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 90: Troubleshooting

    12). To silence the alarm for an existing fault, press any button on the front panel display. If the alarm status changes, the alarm beeps again, overriding the previous alarm silencing. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 91: Table 13. Model List

    47.8" x 12" x 33.5" (121.5 x 30 x 85 cm) 550 lb (250 kg) 3-High UPS-64 47.8" x 12" x 33.5" (121.5 x 30 x 85 cm) 590 lb (268 kg) Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 92: Table 15. Environmental And Safety Specifications

    >0.99 at full load nominal line conditions Input Rated Voltage 100/200, 110/220, or 120/240 Vac with 180° phase displacement 120/208 or 127/220 Vac with 120° phase displacement Input Frequency Range 45–65 Hz Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 93: Table 17. Model Specifications

    Output Peak Current Efficiency (Minimum) 5582 5582 5582 5582 5582 Power Dissipation (BTU/hr) DC Voltage (Supply) 12 kVA Model Output Voltage (Line Line) Output Voltage (Line Neutral) Input Current* Output Current Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 94 Output Voltage (Line Neutral) Input Current* Output Current Output kVA (Line–Line Loads) Output kVA (Line–Neutral Loads) Output kW Output Peak Current Efficiency (Minimum) 3300 3300 3300 3300 3300 Power Dissipation (BTU/hr) Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...

  • Page 95: Table 18. Battery Specifications

    12 kVA/10.8 kW 10 kVA/9 kW 8 kVA/7.2 kW 3-High Cabinets 64 Internal UPS (1) EBM-96 (2) EBM-96 (3) EBM-96 Load Batteries 15 kVA/13.5 kW 12 kVA/10.8 kW 10 kVA/9 kW Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 96 Product Specifications Table 19. Battery Runtimes (in Minutes) at Full Load (Continued) 8 kVA/7.2 kW NOTE Battery times are approximate and vary depending on the load configuration and battery charge. Eaton 9155 UPS (8–15 kVA) User’s Guide 164201553—Rev H0...
  • Page 97 C C h h a a p p t t e e r r 1 1 1 1 W W a a r r r r a a n n t t y y For warranty information, please refer to the Resources link on our website, www.eaton.com/9155.
  • Page 98 164201553H0 164201553 H0...
