- Page 1 9125 Seismic Kit INSTALLATION INSTRUCTIONS For use with Two-in-One 2500–3000 VA Models www.powerware.com...
- Page 2 Powerware is a registered trademark of Powerware Corporation. Copyright 2003 Powerware Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Powerware Corporation.
- Page 3 Powerware 9125 (2500–3000 VA) Seismic Kit The Powerware 9125 (2500–3000 VA) seismic kit is available in two models: a four-unit model and a six-unit model. The four-unit model can secure up to four UPS, battery, or PowerPass Distribution Module (PDM) cabinets;...
- Page 4 Powerware 9125 (2500–3000 VA) Seismic Kit The following steps explain how to install the seismic kit. If you are bolting the cabinet to the floor, use the following drill patterns to prepare the floor mounting holes. 43.00 cm (16.93 in) Ø1.43 cm...
- Page 5 Powerware 9125 (2500–3000 VA) Seismic Kit 60.40 cm (23.78 in) Ø1.43 cm (0.56 in) 53.96 cm 60.85 cm (21.24 in) (23.96 in) 65.41 cm (25.75 in) Figure 3. Drill Pattern for the Six-Unit Model Powerware 9125 (2500–3000 VA) Seismic Kit Installation Instructions Rev A www.powerware.com...
- Page 6 Powerware 9125 (2500–3000 VA) Seismic Kit Attach the front and back straps to the base using the supplied M6 ´ 16 hex bolts and lockwashers (see Figure 4). Verify the straps align with the front and back edges of the base.
- Page 7 Powerware 9125 (2500–3000 VA) Seismic Kit On the back of each cabinet, remove the screw on the top left corner and discard (see Figure 6). Figure 6. Removing Cabinet Screws Beginning with a middle position, slide each cabinet into place.
- Page 8 Powerware 9125 (2500–3000 VA) Seismic Kit Attach the cabinet to the tab on the back strap by installing one of the supplied M4 ´ 10 Phillips hex-head screws (see Figure 8). Figure 8. Securing the Cabinet to the Back Strap Fasten the top of the cabinet to the front strap with two of the supplied M4 ´...
- Page 9 Powerware 9125 (2500–3000 VA) Seismic Kit Install the remaining cabinets, leaving any empty slots to the outside position(s). If there is an empty slot, install spacers to complete the seismic kit. Attach the spacer to the front and back straps using the supplied M4 ´...
- Page 10 Powerware 9125 (2500–3000 VA) Seismic Kit Powerware 9125 (2500–3000 VA) Seismic Kit Installation Instructions Rev A www.powerware.com ®...
