2.1.3 Home key

By pressing the home key, the program will return to the main menu. There is one exception, when the string
edit is activated, the home key will leave the string edit mode.

2.1.4 Edit keys

With the edit keys, the value of the current selected variable can be changed. When the current selection is
not a variable, nothing will happen.
2.2

Display

The display area is divided in a number of areas which have always the same functionality, the following sections:
Title area
Main area
Date/time area
Function key area
2.3

Buzzer

The buzzer will beep shortly to confirm that a key is pressed by the user. The volume of the buzzer can be
changed in the configuration menu section user control.
Shows the current menu title.
Shows the current menu. When a scrollbar is visible to the right of the main area means
that the current menu has some items which are not visible. The size of the shutter repre-
sents the visible area, the position of the shutter indicates the current position. The current
selection can be changed by pressing the cursor movement keys.
Shows the current day of week, date and time.
Shows the functionality of the function key to the right side. The functionality can be
shown by a icon or by plain text.
