Power supplies • Reset circuit • Clocks and crystal oscillators • • Introduction This application note describes a common checklist which should be used when ® ® ® starting and reviewing the schematics for an Atmel XMEGA C design. 8466A−AVR−06/2013...
The BEAD should provide enough impedance (for example, 220Ω at 100MHz, rated current 200mA, that is, Murata BLM15BB221SN1D) for separating the digital power to the analog power. Atmel AT01607: XMEGA C Schematic ChecklistAtmel AT01607: XMEGA C Schematic Checklist [APPLICATION NOTE] 8466A−AVR−06/2013...
External analog reference connections Atmel AVR XMEGA C proposes one ADC using internal references or an external analog reference (AREFA on PORTA). The following schematic checklist is only recommended if the design is using the external analog reference. If the internal reference is used, the circuit is not necessary.
XTAL1 XTAL1 is used as input for an external clock signal Input for inverting oscillator pin 1 XTAL2 Can be left unconnected or used as GPIO Atmel AT01607: XMEGA C Schematic ChecklistAtmel AT01607: XMEGA C Schematic Checklist [APPLICATION NOTE] 8466A−AVR−06/2013...
ESR must be taken into consideration. Both values are specified by the crystal vendor. The Atmel AVR XMEGA C oscillator is optimized for very low power consumption, and thus when selecting crystals, see Table 3-3 for maximum ESR recommendations on 9pF and 12.5pF crystals.
Page 7
System” and “AVR4100: Selecting and testing 32kHz crystal oscillators for Atmel AVR microcontrollers”. Load capacitors should be placed close to the crystal, GND and device oscillator pins. Atmel AT01607: XMEGA C Schematic ChecklistAtmel AT01607: XMEGA C Schematic Checklist [APPLICATION NOTE] 8466A−AVR−06/2013...
10 kΩ 2x3 header PDI_CLK RESET The connector pinout that is shown in Figure 4-1 mates with Atmel tools like the Atmel AVR JTAGICE 3 and Atmel AVR ONE! Table 4-1. PDI port interface checklist. Signal name Recommended pin connection...
The impedance of the USB differential data line pair is 90Ω to each other and 45Ω to ground. The termination of the line is included within the Atmel AVR XMEGA C device as serial resistors. To ensure proper signal integrity, the two D+/D- signals must be closely routed on the PCB (Refer to “AVR1017: XMEGA - USB Hardware Design...
The datasheet and the manual contain block diagrams of the peripherals and details about implementing firmware for the device. The datasheet and the manual are available on http://www.atmel.com/AVR in the Datasheets & Manuals section. Atmel AT01607: XMEGA C Schematic ChecklistAtmel AT01607: XMEGA C Schematic Checklist [APPLICATION NOTE] 8466A−AVR−06/2013...
Revision History Doc. Rev. Date Comments 8466A 06/2013 Initial document release Atmel AT01607: XMEGA C Schematic ChecklistAtmel AT01607: XMEGA C Schematic Checklist [APPLICATION NOTE] 8466A−AVR−06/2013...
