2.2

Unpacking Precautions

Some components on ROCKY-772EV SBC are very sensitive to
static electric charges and can be damaged by a sudden rush
of power. To protect it from unintended damage, be sure to
follow these precautions:
Ground yourself to remove any static charge before touching
your ROCKY-772EV SBC. You can do it by using a grounded
wrist strap at all times or by frequently touching any conducting
materials that is connected to the ground.
Handle your ROCKY-772EV SBC by its edges. Don't touch IC
chips, leads or circuitry if not necessary.
Do not plug any connector or jumper while the power is on.
Table of Jumpers
LABEL
JP1 & CPU FSB 200/266MHz Setting
JP7
JP2 Onboard LAN2 enable/disable.
JP3 CompactFlash Master(close)/Slave(open) Setting.
JP4 Onboard LAN1 enable/disable.
JP5 Watch-Dog Active Type Setting
JP6 DiskOnChip Memory Address Setting
JKB1 Keyboard/Mouse power source Setting
JBAT1 CMOS state setting
Note: All shaded rows in tables of this manual are the default settings
for the ROCKY-772EV.
FUNCTION
11
2.3

Setting the CPU of ROCKY-772EV

• JP1 & JP7 : CPU FSB 200/266MHz Setting
CPU FSB
1-2 3-4
200 MHz CLOSE CLOSE OPEN CLOSE CLOSE
266 MHz OPEN OPEN OPEN OPEN OPEN
When you change CPU with FSB 266MHz to that with 200MHz
be sure to clear CMOS before first power ON.
2.4 Watch-Dog Timer (JP5)
Reading I/O port 443H enables the Watch-Dog Timer. It should
be triggered before the time-out period ends, otherwise it will
assume the program operation is abnormal and will issue a
reset signal to start again, or activate NMI to CPU. The Watch-
Dog Timer is disable by reading I/O port 043H or 843H. Refer to
Appendix A for detailed information on Watch-Dog Timer.
• JP5 : Watch-Dog Active Type Setting
JP5
1-2 ACTIVATE NMI TO CPU WHEN WDT TIME-
OUT
2-3 RESET WHEN WDT TIME-OUT
OPEN DISABLE WDT
2.5 DiskOnChip™ Flash Disk
The DiskOnChip™ Flash Disk Chip(DOC) is produced by M-
Systems. Because the DOC is 100% software compatible to
hard disk and DOS, users don't need any extra software utility. It
is just "plug and play" easy and reliable. At present the DOC is
available from 2MB to 144MB. The DiskOnChip only shares
8KB memory address.
JP1 JP7
5-6 7-8 1-2
DESCRIPTION
12
