The IDE adapters control the hard disk drive. Use a separate sub menu
to configure each hard disk drive.
Figure 2 shows the IDE primary master sub menu.
CMOS Setup Utility - Copyright ( C ) 1984-2001 Award Software
IDE Primary Master
IDE HDD Auto-Detection Press Enter
IDE Primary Master Auto 2557 MB
Access Mode Auto
Cylinder 4956
Head 16
Precomp 0
Landing Zone 4955
Sector 63
↑↓←→Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-safe defaults
Figure 2 IDE Primary Master sub menu
Use the legend keys to navigate through this menu and exit to
the main menu. Use Table 3 to configure the hard disk.
Item Options
IDE HDD Auto- Press Enter
detection
IDE Primary Master None
Auto
Manual
Capacity Auto
Item Help
Menu Level
To auto-detect the HDD's size,
head... on this channel
F7:Optimized Defaults
Description
Press Enter to auto-detect
the HDD on this channel. If
detection is successful, it
fills the remaining fields on
this menu.
Selecting 'manual' lets you
set the remaining fields on
this screen. Selects the
type of fixed disk. "User
Type" will let you select the
number of cylinders, heads,
etc. Note:
PRECOMP=65535 means
NONE !
Display Disk drive capacity
31
your disk drive
size
Access Mode Normal
LBA
Large
Auto
The following options are selectable only if the 'IDE Primary Master' item is
set to 'Manual'
Cylinder Min = 0
Max = 65535
Head Min = 0
Max = 255
Precomp Min = 0
Max = 65535
Landing zone Min = 0
Max = 65535
Sector Min = 0
Max = 255
Table 3 Hard disk selections
4.7 Advanced BIOS Features
(Approximated). Note that
this size is usually slightly
greater than the size of a
formatted disk given by a
disk checking program.
Choose the access mode
for this hard disk
Set the number of cylinders
for this hard disk.
Set the number of read/write
heads
**** Warning: Setting
value of 65535 means no
hard disk
****
Number of sectors per track
