RJ45 LAN connectors. There are two LED on the connector
indicating the status of LAN. The pin assignments are as
following:
• CN22(LAN1)/CN24(LAN2): LAN RJ45 Connector
PIN NO. DESCRIPTION
1
TX+
2
TX-
3.
RX+
4.
N/C
• CN17(LAN1)/CN16(LAN2): LAN State LED Connector
PIN NO.
DESCRIPTION
1-2
ACT/LINK
3-4

3.11 VGA Connector

The ROCKY-772EV has a built-in 15-pin VGA connector directly
connects to your CRT monitor.
• CN21 : 15-pin Female Connector
1
RED
2
3
BLUE
4
5
GROUND
6
7
GROUND
8
9
NC
10
11
NC
12
13
HSYNC
14
15
DDCCLK
3.12 AUDIO Headphone & Connector
The ROCKY-772EV has a built-in AC'97 AUDIO CODEC;
connector directly connects to your MIC-IN & CD-IN & LINE-IN.
• CN23: AUDIO Headphone Jack (Output)
• CN19: AUDIO LINE-IN Connector (Input)
• CN20: AUDIO CD-IN Connector (Input)
• CN18: AUDIO MIC-IN Connector (Input)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
5.
N/C
6.
RX-
7.
N/C
8.
N/C
100TX
GREEN
NC
GROUND
GROUND
GROUND
DDC DAT
VSYNC
21
CN20
CN19
1
LEFT
LEFT
2
GND
GND
3
GND
GND
4
RIGHT
RIGHT
3.13 ATX 20-PIN Power Connector (CN1)
This connector supports the ATX power, functions such as
modem Ring on, wake-up LAN and soft power off are supported
by mainboard. (Power source from Mainboard)
PIN NO.
DESCRIPTION
1
3.3V
3
GND
5
GND
7
GND
9
5VSB
11
3.3V
13
GND
15
GND
17
GND
19
5V
4
CN18
MIC-IN
GND
GND
NC
PIN NO.
DESCRIPTION
2
3.3V
4
5V
6
5V
8
PW_OK
10
12V
12
-12V
14
ATX-ON
16
GND
18
-5V
20
5V
22
