Functions In 55-Channel Dmx Mode - thomann Stairville LED Pixel Rail Drive 640 MKII User Manual

6.3 Functions in 55-channel DMX mode

Channel Value
1 0 ... 255
2 0 ... 255
3 0 ... 255
4 0 ... 255
5 0 ... 255
6 0 ... 255
7 0 ... 255
8 0 ... 255
9 0 ... 255
10 0 ... 255
Function
Dimmer function (0 % ... 100 %)
Strobe effect (slow ... fast)
Automatic programme 1 (multi colour effect. The last effect will be played automatically.)
Automatic programme 2 (colour effect. The colour can be selected with CH9. The last
effect will be played automatically.)
Programme speed (slow ... fast)
Colour selection for colour effect in the automatic programme
Microphone sensitivity for sound control (low to high)
Intensity red, first spotlight at the first output
Intensity green, first spotlight at the first output
Intensity blue, first spotlight at the first output
LED Pixel Rail Drive 640 MKII
Operating
35
