Handle With Care - ChargePoint Express 200 Installation Manual

Safety and Operational Ratings
Enclosure Rating
Safety Compliance
Surge Protection
EMC Compliance
Efficiency
Power Factor
Cooling
Operational Altitude
Operational Temperature
Storage Temperature
High Altitude Operating Temperature
Operating Humidity
Terminal Block Specifications
480V Terminal Block
120V Terminal Block
Dimensions and Weights
Dimensions
Installation Footprint
Weight
Shipping Weight
NOTE: ChargePoint, Inc. reserves the right to alter product offerings and specifications at any time without notice,
and is not responsible for typographical or graphical errors that may appear in this document.

Handle with care

Always transport and store the CPE200 in its original packaging in a horizontal position. Unpack and raise
the CPE200 to its vertical position during the installation process only.
Use appropriate lifting equipment (forklift, pallet jack, lifting straps and engine hoist, crane, etc). Ensure all
lifting equipment used is rated for shipping and product weights listed above.
DANGER: Allow the CPE200 to stand in its vertical position only when secured to lifting equipment with the
lifting straps, or when the CPE200 has been bolted to its concrete pad.
Type 3R, IP 65
UL Listed for USA cUL certified for Canada: complies with UL 2202,
UL 2231-1, UL 2231-2
6kV @ 3,000A. In geographic areas subject to frequent thunderstorms,
supplemental surge protection at the service panel is recommended.
FCC Part 15, Subpart B
>92%
>0.99
Liquid Cooled
<6,000 feet (<1828 meters)
-31 °F to 122 °F (-35 °C to 50 °C)
-31 °F to 122 °F (-35 °C to 50 °C)
6000–8000' (1800–2400 m): -31 °F to 104 °F (-35 °C to 40 °C). Output
power derating may apply.
Up to 95% @ 122 °F (+50 °C) non-condensing
Temperature Rating: 90 °C
Tightening Torque: 31 in-lbs (3.5 Nm)
Wire Size: 4-2 AWG (21–34 mm2)
Temperature Rating: 90 °C
Tightening Torque: 14 in-lbs (1.6 Nm)
Wire Size: 14 –12 AWG (2.1–3.3 mm2)
HxWxD: 79" x 30" x 13" (2,000mm x 750mm x 330mm)
WxD: 23" x 11" (580mm x 270mm)
364 lb (165 kg)
728 lb (330 kg)
Introduction
1 - 3
