Gira System 106 Installation Instructions

Installation
en
instructions
System 106
Surface-mounted housing
1- to 5-gang
5501 9..
5502 9..
5503 9..
5504 9..
5505 9..
5508 9..
For your safety
Electrical devices may only be installed and
connected by a qualified electrician.
These instructions are part of the product and
must remain with the end customer.
Read the instructions before use and
observe the information.
Mounting example: surface-mounted housing,
2-gang.
Dimensions
1 x 1 1 x 4
b
a
1 x 3
1 x 2
110 mm
a
1 x 1 = 106,5 x 106,5 mm
1 x 2 = 106,5 x 213,0 mm
2 x 2 = 213,0 x 213,0 mm
1 x 3 = 106,5 x 319,5 mm
1 x 4 = 106,5 x 426,0 mm
1 x 5 = 106,5 x 532,5 mm
Scope of supply
01
02
03
04
05
06
07
08
Mounting examples
1 x 5
2 x 2
b
01 0 2
1 x Drilling template
1 x Function carrier
1 x Housing
2 x Screw and dowel set
(ø 6 mm)
1 x Safety bond
1 x System cables and
terminating resistors
(from 2-gang housing)
1 x Bit holder and bit
1 x Installation instructions
22 22
03 0 4
08 07
de Gehäuse Aufputz 1 bis 5fach
nl
Gehäuse Aufputz 1 bis 5fach
fr Gehäuse Aufputz 1 bis 5fach
en
Gehäuse Aufputz 1 bis 5fach
22 22
05
06
