Table 3-5. J3 Pci Bus Connector Pin Assignment - Motorola 82543 Owner's Manual

J3 PCI Bus Connector
3
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
3-8
Note: An asterisk (*) in a signal name indicates that the signal is active
low.

Table 3-5. J3 PCI Bus Connector Pin Assignment

Signal
NC
GND
C/BE6*
C/BE4*
V(I/O)
AD63
AD61
GND
AD59
AD57
V(I/O)
AD55
AD53
GND
AD51
AD49
GND
AD47
AD45
V(I/O)
AD43
AD41
GND
AD39
AD37
Signal
GND
C/BE7*
C/BE5*
GND
PAR64
AD62
GND
AD60
AD58
GND
AD56
AD54
GND
AD52
AD50
GND
AD48
AD46
GND
AD44
AD42
GND
AD40
AD38
GND
Gigabit Ethernet/82543 PMC Installation and Use
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
