Installation and Removal
1
!
Caution
1-14
Insert the board by gently holding the injector levers - do not exert
unnecessary pressure on the faceplate.
Hot swap compliant modules may be installed while the system is powered
on. If a module is not hot swap compliant, you should remove power to the
slot or system before installing the module. See
page 1-8 for more information.
Refer to the Figure 1-4
Note that this illustration is for general reference only and may not
accurately depict the connectors and handles on the board you are
installing.
Stage 1

Figure 1-4. General Host Board Installation

1. Open the injector levers on your board (see
Injector/Ejector Lever Types on page
2. Verify the proper slot for the module you are inserting (see
Slot Usage on page
card cage rail guides in the appropriate slot.
3. Using your thumbs, apply equal and steady pressure as necessary to
carefully slide the module into the card cage rail guides (Stage 1).
and perform these steps when installing modules.
Stage 2
(Detail)
J5
J4
J3
J2
J1
Stage 2
1-9).
1-10). Align the edges of the module with the
Gigabit Ethernet/82543 PMC Installation and Use
Understand Hot Swap on
J5
J4
J3
J2
J1
4200 0804
Stage 3
Recognize Different
Verify
