Table 3-2. J1 PCI Bus Connector Pin Assignments (Continued)
Pin Signal
57 V(I/O)
59 AD02
61 AD00
63 GND

Table 3-3. J2 PCI Bus Connector Pin Assignments

Pin Signal
1 +12V
3 TMS
5 TDI
7 GND
9 NC
11 BUSMODE2*
13 RST*
15 +3.3V
17 NC
19 AD30
21 GND
23 AD24
25 IDSEL
27 +3.3V
29 AD18
31 AD16
33 GND
35 TRDY*
37 GND
39 PERR*
41 +3.3V
Gigabit Ethernet/82543 PMC Installation and Use
J1 and J2 PCI Bus Connectors
Signal
AD03
AD01
+5V
REQ64*
Signal
TRST*
TDO
GND
NC
NC
+3.3V
BUSMODE3*
BUSMODE4*
GND
AD29
AD26
+3.3V
AD23
AD20
GND
C/BE2*
NC
+3.3V
STOP*
GND
SERR*
Pin
58
3
60
62
64
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
3-5
