Johnson Controls LN-IO -1 Series Installation Instructions Manual page 23

Table 8: LN-PRG400-2 and LN-PRG410-2 Programmable Controllers (Part 2 of 2)
1
Outputs
Electromagnetic Compatibility
Compliance
1. Floating available when programmed with LN GPI software.
2. All materials and manufacturing processes comply with the RoHS directive and are marked according to the Waste
Electrical and Electronic Equipment (WEEE) directive.
Table 9: LN-PRG500-2 and LN-PRG510-2 Controllers (Part 1 of 2)
Product Codes
Power Requirements
Environmental
General
Enclosure
LN Application Specific, Remote I/O, and Free Programmable Controllers Installation Instructions
Software and jumper configurable
0 to 10 VDC, digital 0 to12 VDC (on/off), PWM, or Floating
PWM output: adjustable period from 2 seconds to 15 minutes
Floating control: requires two consecutive output
minimum pulse on/off: 500 milliseconds
adjustable drive time period
60 mA maximum at 12 VDC (60ºC [140ºF])
Minimum load 200 ohms
Auto reset fuse
60 mA at 60ºC (140ºF)
100 mA at 20ºC (68ºF)
Output Resolution: 10-bit digital/analog converter
Power Supply Output: 15 VDC, maximum 240 mA
CE Emission: EN61000-6-3: 2007 Generic standards for residential, commercial, and
light-industrial environments.
CE Immunity: EN61000-6-1: 2007; Generic standards for residential, commercial, and
light-industrial environments.
United States: UL Listed: UL916 Energy management equipment
2
Material : UL94-5VA
Canada: UL Listed: UL916 Energy management equipment
2
Material : UL94-5VA
LN-PRG500-2 and LN-PRG510-2
Voltage: 24 VAC/DC; +/- 15%, 50/60 Hz, Class 2
Protection: 3.0 A user-replaceable fuse
Typical Consumption: 25 VA all outputs with 20mA load at 12 VDC and 15 VDC output
80mA (4 x 20 mA)
Maximum Consumption: 50 VA
Operating Temperature: 0 to 70
Storage Temperature: -20 to 70
Relative Humidity: 0 to 90%
Standard: L M Functional Profile: SCC-VAV Controller #8502
ON ARK
Processor: Neuron 3150, 8 bits, 10 MHz
Memory: Nonvolatile Flash 64k (APB application), Nonvolatile Flash 64k (storage)
Media Channel: TP/FT-10; 78 Kbps
Communication: LonTalk protocol
Transceiver: FTX-1
L M Interoperability: Version 3.4
ON ARK
Device Class: Multi I/O Module
L M Functional Profile: Input Objects: Open-Loop Sensor #1, Output Objects:
ON ARK
Open-Loop Sensor #3
Material: ABS type PA-765A
Dimensions (with screws): 7.7 x 4.7 x 2.0 in. (195.6 x 119.4 x 50.8 mm)
Shipping Weight: 1.17 lb (0.53 kg))
23
° °
C, (32 to 158 F)
° °
C, (-4 to 158 F)
