LN Series Line Powered Fan Coil Unit Controller (PFCU)
Installation Instructions
LN-PFCUA-1, LN-PFCU-1
Application Requirements
Follow these recommendations for proper installation
and subsequent operation of each controller:
Keep the controller at room temperature for at least
24 hours prior to installation to ensure evaporation
of condensation that may have accumulated due to
low temperature during shipping.
Properly inspect the product for shipping damage.
Do not install damaged controllers.
Record the Neuron® ID located on both sides of
the device to commission the device later.
Ensure proper clearance and ventilation for the
controller. Position the controller with the
ventilation slots and power supply/output terminal
block connector towards the top for safety and to
allow proper heat dissipation.
Operate the controller under the following
conditions:
-
Ambient temperature: 32 to 158°F (0 to 70°C)
-
Relative humidity: 0 to 90%, noncondensing
IMPORTANT: Prevent any static electric discharge
to the controller. Static discharge can damage the
controller and void the warranties.
North American Emissions Compliance
United States
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Industry Canada Statement
Le terme « IC » précédant le numéro d'accréditation/
inscription signifie simplement que le produit est conforme
aux spécifications techniques d'Industry Canada.
Mounting
You can mount each controller on a DIN rail, in a panel,
or on a wall. The controllers are equipped with
2 mounting holes measuring 0.25 x 0.165 in.
(6.35 x 4.191 mm).
DIN Rail
To mount the controller on a DIN rail:
1. Ensure the DIN rail is properly mounted on the
wall.
2. Clip the controller onto the DIN rail.
LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation
Code No. LIT-12011319
Issued April 24, 2014
Supersedes November 9, 2007
Instructions
1

Advertisement

Table of Contents
loading

Summary of Contents for Johnson Controls LN Series

  • Page 1 DIN Rail To mount the controller on a DIN rail: 1. Ensure the DIN rail is properly mounted on the wall. 2. Clip the controller onto the DIN rail. LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 2: Wall Mount

    D ig ita l Dry Co n ta ct must remain between 18 to 14 AWG NO -NC CO M in diameter. Figure 4: Digital Dry Contact (NO and NC) LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 3: Output Wiring

    LN-PFCUA-1 controllers have two universal outputs. The outputs are all software configurable. Note: Before you connect output equipment to the controller, refer to the installation instructions from the equipment manufacturer. LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 4 They must be at least 18 AWG if they are switching Floating Actuator Powered by high voltage. External 85-265 VAC Power Supply • connect an external load to measure the state of a triac output LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 5: Communications Wiring

    Neuron chip’s memory; the chip is then in an application-less state. The memory erase jumper is labeled J5 on the LN-PFCU controllers. LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 6 Note: You must use the Load or Commission option in LN-Builder 3 if the controller already exists in the LNS database to download the APB file. Do not use the Replace option. LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 7 Dispose of products at the end of their useful life • clean the outside of the front plate and/or the inside according to local regulations and the WEEE Directive. of the back plate, using a dry cloth LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 8 Figure 21: Wiring Diagram - Typical Fan Coil Application LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 9: Troubleshooting

    Hardware input is not reading the correct value. Input Wiring Problem Check that the wiring is correct according to this manual and according ’ to the peripheral device s manufacturer. LN Series Line Powered Fan Coil Unit Controller (PFCU) Installation Instructions...
  • Page 10: Repair Information

    APB or NXE into the controller using LN-Builder 3 or another network management tool. Repair Information If the LN Series Powered Fan Coil Unit controller fail to operate within its specifications, replace the unit. For a replacement controller, contact the nearest Johnson Controls representative.
