LN Series Variable Air Volume (VAV) LN-VAVCF-12
Controller
Installation Instructions
LN-VAVCF-12
Application
The LN Series Variable Air Volume (VAV)
LN-VAVCF-12 controller is designed to control various
types of variable air volume equipment.
The controller is based on L
peer-to-peer communication between controllers and is
L
M
® network certified.
ON
ARK
Note: You can configure the LN-VAVCF-12 controllers
using the LN Series Variable Air Volume Preloaded
Application. For more information regarding
configuration using the preloaded application, refer to
the LN Series Variable Air Volume (VAV) Preloaded
Application User's Guide (LIT-12011830).
North American Emissions Compliance
United States
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2. This device must accept any interference
received, including interference that may cause
undesired operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
Canada
Industry Canada Statement
The term IC before the certification/registration
number only signifies that the Industry Canada
technical specifications were met.
Le terme « IC » précédant le numéro d'accréditation/
inscription signifie simplement que le produit est
conforme aux spécifications techniques d'Industry
Canada.
LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions
W
® technology for
ON
ORKS
Supersedes January 30, 2013
Installation
For proper installation and subsequent operation of the
LN-VAVCF-12 controller, follow these
recommendations:
Inspect the controller for shipping damage. Do not
install damaged devices.
Allow for proper clearance of device casing, wiring
terminals, and service pin for easy access,
hardware configuration, and maintenance.
The controllers are designed to operate under the
following conditions:
Ambient temperature between 32 to 122°F
(0 to 50°C)
Relative humidity from 0 to 90%,
noncondensing
Ensure proper ventilation of devices and avoid
areas where corroding, deteriorating, or explosive
vapors, fumes, or gasses may be present.
Record the Neuron® ID located on the box and on
the side of the controller. You need it for
commissioning the device.
IMPORTANT: Work in a static-free area. Discharge
any static electricity you may have accumulated.
Discharge static electricity by touching a known,
securely grounded object. Do not handle the
controller without proper protection against static
discharge. Use a wrist strap when handling the
controller. Secure the wrist strap clamp to earth
ground.
Code No. LIT-12011802
Issued April 24, 2014
1

Advertisement

Table of Contents
loading

Summary of Contents for Johnson Controls LN Series

  • Page 1 Industry Canada technical specifications were met. Le terme « IC » précédant le numéro d'accréditation/ inscription signifie simplement que le produit est conforme aux spécifications techniques d'Industry Canada. LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 2 Dimensions Figure 1: LN-VAVCF-12 Dimensions, mm (in.) Figure 2: LN-VAVCF-12 Components LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 3 9. Connect the VAV box flow sensor tubing to the the warranty. controller’s Pressure Sensor Inputs. Create a condensation trap in the pneumatic tubing by forming it into a vertical loop. LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 4 (VAV) ou le réseau de conduites au démarrage de l'unité de traitement d'air. Figure 5: Typical Power and Network Connections with an LN Series Communicating Sensor Input and Floating Actuator Output LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 5: Power Wiring

    Avoid installation conditions that fall outside the parameters of Table 1. • Keep input and output wiring in conduits, trays, or close to the building frame, if possible. LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 6: Input Wiring

    30 m (100 feet) Typical VAV controller with one LN Series Communicating Sensor and actuator active. No external loads. Typical VAV controller with one LN Series Communicating Sensor, 2 TRIAC loads (1.6 VA each), 1 analog output (20 mA), and actuator active.
  • Page 7 Figure 12: Current Input – 2-Wire menus. Connect the LN Series Communicating Sensor Transducer Powered by the Controller to the controller with a standard Category 5e Ethernet patch cable fitted with RJ-45 connectors. LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 8: Output Wiring

    1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 IMPORTANT: Protect the controller’s connector from being pulled on when a cable to the LN Series Communicating Sensor is connected. Create a Stripe Solid...
  • Page 9 Wave Modulation (PWM) signal or a simple two-state signal. These outputs are protected by an auto-reset fuse. Wiring Discrete Outputs If a 12 VDC relay is being controlled, connect it to a universal output (Figure 23). LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 10 ORKS The Cat 5e cable length may also be restricted by the maximum allowable subnetwork bus length. For more information, refer to the LN Series Communicating Sensors Installation Instructions (LIT-12011795). LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 11: Wireless Installation

    Each controller has a wireless port where you connect is undone. the telephone cable. Uncover the controller to locate the wireless port on the PCB board (marked as Wireless Module). LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 12: Terminal Block Cover

    Verify the transformer used is powerful enough to supply all transformer controllers. Network not wired property Double-check the wire connections are correct. Absent or incorrect network Check the network terminator(s). terminators LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 13 Ensure the high and low pressure sensors are not inverted. Device is not calibrated Recalibrate the VAV controller. Refer to the controller user properly guide for more information about VAV controller calibration. LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 14: Status Led Operation

    Receiver. Refer to the LN Series Wireless Solution Guide Technical Bulletin (LIT-120116828). Configuration Problem Using the device configuration plug-in or wizard, check the configuration of the input. Refer to the LN Series Wireless Solution Guide Technical Bulletin (LIT-12011628) Damper is not opening or Mechanical stops not in The two mechanical stops must be positioned to stop the closing properly.
  • Page 15: Technical Specifications

    Programmable Device: Static Programmable Device #410, SCC VAV #8502 Enclosure Material: FR/ABS Dimensions (with screws): 4.8 x 8.4 x 2.5 in. (122.7 x 214.3 x 63 mm) Shipping Weight: 2.30 lb (1.05 kg) LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 16 PWM control: adjustable period from 2 to 65 sec Floating control: minimum plus on/off: 500 ms adjustable drive time period 20 mA maximum at 12 VDC Minimum load resistance 600 ohms Output Resolution: 10-bit digital/analog converter LN Series Variable Air Volume (VAV) LN-VAVCF-12 Controller Installation Instructions...
  • Page 17 Floating only available when controller is programmed with LN GPI software. You cannot use an LN Series Communicating Sensor and Wireless Receiver at the same time. However, you can temporarily connect an LN Series Communicating sensor to a controller in wireless mode to perform VAV airflow balancing.
