Johnson Controls LN-IO -1 Series Installation Instructions Manual page 17

Table 4: LN Application Specific Controllers
Electromagnetic Compatibility
Compliance
1. All materials and manufacturing processes comply with the RoHS directive and are marked according to the Waste
Electrical and Electronic Equipment (WEEE) directive.
Table 5: LN Remote I/O Modules
Product Codes
Power Requirement
Environmental
General
Enclosure
LN Application Specific, Remote I/O, and Free Programmable Controllers Installation Instructions
CE Emission: (CDN and US)
CE Immunity: Material
EN61000-4-2: 1995, level 2 by contact
EN61000-4-3: 1996, level 2
EN61000-4-4: 1995, level 2
EN61000-4-6: 1996, level 2
ENV 5024: 1995, level 2
FCC: This device complies with FCC rules part 15, subpart B, class B
United States: UL916 Energy Management Equipment
1
Material : UL94-5VA
Canada: UL916 Energy Management Equipment
1
Material :UL94-5VA
Europe: CE Mark – Johnson Controls, Inc. declares that the products are in compliance
with the essential requirements and other relevant provisions of EMC Directive 2004/
108/EC.
LN-IO301-1, LN-IO401-1, LN-IO520-1
Voltage: 24 VAC/DC; ±15%, 50/60 Hz, Class 2
Protection: 1.35 A auto-reset fuse
Power Consumption: 6 VA typical
Maximum Consumption: 15 VA
Operating Temperature: 0 to 50
Storage Temperature: -20 to 70
Relative Humidity: 0 to 90% noncondensing
Processor: Neuron® 3150™; 8 bits
Processor Speed: 10 MHz
Memory: 64k Nonvolatile Flash (APB application and configuration properties)
Communication: LonTalk® protocol
Transceiver: FT-X1
Status Indicator: Green LED - power status and LON TX, Orange LED - service and LON
RX
Communication Jack: LON® mono audio jack 1/8 in. (3.5 mm)
Material: ABS PA-765A
Dimensions (with screws):
LN-IO301-1: 5.7 x 4.7 x 2.0 in. (144.8 x 119.4 x 50.8 mm)
LN-IO401-1 and LN-IO520-1: 7.7 x 4.7 x 2.0 in. (195.6 x 119.4 x 50.8 mm)
Shipping Weight:
LN-IO301-1:.77 lb (0.35 kg)
LN-IO401-1 and LN-IO520-1: .86 lb (0.39kg)
17
° °
C, (32 to 122 F)
° °
C, (-4 to 158 F)
