36 Chassis installation fundamentals
Table 2
Accessories shipped with the 8010, 8006, and 8003 chassis (cont'd.)
Check
Accessory
Side cable management brackets
•
two brackets for the 8010 chassis
•
one bracket each for the 8006 and 8003
chassis
Rubber footpads
Console cable
Figure 5 "Items in the 8010 chassis shipping container" (page
6 "Items in the 8006 chassis shipping container" (page
7 "Items in the 8003 chassis shipping container" (page 38)
items in the chassis shipping container.
Figure 5
Items in the 8010 chassis shipping container
Copyright © 2008 Nortel Networks
.
Nortel Ethernet Routing Switch 8600
Installation — Chassis
NN46205-303 02.01 Standard
30 May 2008
Usage
Manage network interface cables.
Keep the chassis from slipping when
you mount it on a flat surface.
Connect an optional management
console to the chassis. Each end of
the console cable uses a DB-25 and
a DB-9 connector.
37), and
illustrate the
36),
Figure
Figure
