30 Chassis installation fundamentals
Figure 2
8010 chassis and components
The 8010 chassis has three power supply bays. The Ethernet Routing
Switch 8600 can be configured for AC input or DC input applications or site
installations. The 8010 chassis supports the following AC power supplies:
•
•
•
•
The 8010 chassis supports the following DC power supplies:
•
•
•
ATTENTION
R or RS modules installed in the 8006, 8010, or 8010co chassis require a
minimum of one 8005AC, 8005DI AC, or 8005DC power supply.
If your Ethernet Routing Switch 8600 is operating in a redundant power
configuration, you can upgrade the Ethernet Routing Switch 8600 for
additional power while the Ethernet Routing Switch 8600 remains in
operation.
Copyright © 2008 Nortel Networks
.
8001AC (discontinued)
8004AC
8005AC
8005DI AC
8002DC (discontinued)
8004DC
8005DC
Nortel Ethernet Routing Switch 8600
Installation — Chassis
NN46205-303 02.01 Standard
30 May 2008
