Summary of Contents for KTM 1290 Super Duke R 2016
- Page 1 SETUP INSTRUCTIONS 2016 1290 Super Duke R Art. no. 3213441en...
- Page 3 KTM accepts no liability for delivery options, devi- ations from illustrations and descriptions, misprints, and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 SETUP Unpacking and setting up the vehicle Preparatory work – Remove the box. Main work – Remove the adhesive tape in the upper area of the motorcycle. L01494-01 – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have finished work on the vehicle.
- Page 6 (Super Duke R Special Edition) – Remove the mounted clutch and brake levers. L01506-01 – Unpack and mount the KTM PowerParts levers included in the delivery. V00184-01 – Mount the clutch and brake lever protection. – Check the throttle grip for smooth operation.
- Page 7 (Super Duke R Special Edition) – Take off the mounted clutch reservoir and brake fluid reservoir lids. – Unpack and mount the KTM PowerParts lids included in the delivery. V00187-01 – Take off the mounted foot brake cylinder lid. –...
- Page 8 Plug in the connector of starter relay – Recharge the battery. ( p. 9) – Remove the protective plastic. – Refuel. ( p. 10) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer. L01508-10...
- Page 9 WORK Removing the passenger seat – Insert the ignition key in seat lock and turn it clockwise. – Lift the passenger seat at the front and pull it out of the holder toward the front. – Remove the passenger seat. –...
-
Page 10: Installing The Battery
WORK Removing the battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep batteries out of the reach of children. – Wear suitable protective clothing and goggles. – Avoid contact with battery acid and battery gases. –... - Page 11 Environmental hazard The battery contains elements that are harmful to the environment. – Do not dispose of batteries with the household waste. Dispose of a defective battery in an environmentally friendly manner. Give the battery to your authorized KTM dealer or dispose of it at a collection point for used batteries.
- Page 12 WORK Warning Environmental hazard Hazardous substances cause environmental damage. – Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations. Info Even when there is no load on the battery, it discharges steadily. The charging level and the method of charging are very important for the service life of the battery. Rapid recharging with a high charging current shortens the service life of the battery.
- Page 13 WORK – Only refuel with clean fuel that meets the specified standards. Warning Environmental hazard Improper handling of fuel is a danger to the environment. – Do not allow fuel to get into the ground water, the ground, or the sewage system. –...
- Page 14 WORK 3.10 Closing the filler cap – Fold down filler cap – Turn ignition key clockwise. L01420-10 – Press down the filler cap and turn back ignition key until the fuel tank lock locks. Warning Fire hazard Fuel is highly flammable, poisonous and harmful to your health.
-
Page 15: Technical Data
TECHNICAL DATA chassis tightening torques – EJOT PT ® Remaining screws, chassis K50x12 1 Nm (0.7 lbf ft) – Remaining screws, chassis EJOT PT ® K50x14 1 Nm (0.7 lbf ft) – Remaining screws, chassis EJOT PT ® K50x16 2 Nm (1.5 lbf ft) –... - Page 16 TECHNICAL DATA – Nut, rear sprocket 36 Nm (26.6 lbf ft) – Nut, shift rod 12 Nm (8.9 lbf ft) – Nut, shift rod M8LH 12 Nm (8.9 lbf ft) – Nut, valve, angled 4 Nm (3 lbf ft) – Remaining nuts, chassis 25 Nm (18.4 lbf ft) –...
- Page 17 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
- Page 18 *3213441en* 3213441en 03/2016 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
