  • Page 1 Head-End Digital Modulator HDTV / COFDM HDTV 1000 T HDTV 1001 T CLASS Phone: +49 (0) 911 / 703 8877 Grundig SAT Systems GmbH Fax: +49 (0) 911 / 703 9210 Beuthener Strasse 43 E-mail: info@gss.de D-90471 Nuremberg Internet: http://www.gss.de...
  • Page 2: Table Of Contents

    Selecting channel / frequency setting ............23 Setting the output channel ................24 Setting the output frequency ................24 Switching the modulator off or on ..............24 Adjusting the output levels of the channel strips ..........25 - 2 - HDTV 1000 T / HDTV 1001 T...
  • Page 3 5.4.1 Operation with a CA module ............43 Setting the scrambling ..............43 Setting the PID monitoring ..............44 Configuring the CA module ..............44 Setting the station filter ..............45 6 Final procedures .....................46 7 Channel and frequency tables .................47 - 3 - HDTV 1000 T / HDTV 1001 T...
  • Page 4: Safety Regulations And Notes

    Test the software versions of the head-end station and the cassette and update them if necessary. The current software versions can be found at ”www.gss.de”. General information Packing contents - 4 - HDTV 1000 T / HDTV 1001 T...
  • Page 5: Meaning Of The Symbols Used

    Transmission modes: ..............Types of modulation: ........Code rates: .............. Guard intervals:............HF output Frequency range: ..........Channels: ............Types of modulation: ........Output level: ................96 dBµV Output impedance: ................. 75 - 5 - HDTV 1000 T / HDTV 1001 T...
  • Page 6: Description

    The transport stream fed via the ASI socket can be inserted into the transport streams of the receiving stages via the TPS module. The signal path is set in the menu items input signal path “INROUTE” and output signal path ”OUTROUTE”. - 6 - HDTV 1000 T / HDTV 1001 T...
  • Page 7: 2.4.1 Input Signal Path "Inroute

    “TS ASI” are split into transport stream 1 and 2. Receiving stage “B” is not used. TS    A Receiving  stage CA  module Transport  stream  1 SAT  input    ”A“ "A" TS    ASI ASI  input     Transport  stream  2 - 7 - HDTV 1000 T / HDTV 1001 T...
  • Page 8: 2.4.2 Output Signal Path "Outroute

    ASI output and the transport stream from the ASI input “TS ASI” via modulator “B” (MB). Modulator Transport  stream  1 "A" Combiner HF  output TS    ASI Modulator   ASI  input "B" Transport  stream  2 ASI  output - 8 - HDTV 1000 T / HDTV 1001 T...
  • Page 9: 2.4.3 General

    “Bx …A” and “Bx …B”. Using an adequate CA module encoded chan- nels can be decoded via channel strip “A”. In addition cassette HDTV 1000 T is able to encode uncoded channels via an adequate CA module. The control of the cassette takes place via the control unit of the head-end station.
  • Page 10 Changing the operator ID (CAT) Some network operators transmit an operator ID in the data stream (e.g. visAvision). By changing the CAT the operator ID can be adjusted to the cur- rent demands. - 10 - HDTV 1000 T / HDTV 1001 T...
  • Page 11: Assembly

    19” cabinet, make sure the connections leading in and out for the 19” cabinet are made using cable terminals. The attenuation of shielding of the connection lines for ASI and antenna must meet the requirements for “Class A”. CLASS - 11 - HDTV 1000 T / HDTV 1001 T...
  • Page 12: Connecting The Cassette

    The operating software of the cassette can be updated via the 9-Pin D-SUB socket “RS-232” using a PC or notebook and the software “BE-Flash”. You can find the current operating software on the website “www.gss.de”. - 12 - HDTV 1000 T / HDTV 1001 T...
  • Page 13: Retrofitting A Ca Module

    (top) of the CA module. (see chap. 3.3) with the top side of the CA module facing the top side of the cassette. and contact it to the common interface. - 13 - HDTV 1000 T / HDTV 1001 T...
  • Page 14: The Control Panel At A Glance

    The key pad on the head-end station is used to scroll through the menus step-by-step: scrolls forward through the menus. select parameters in the menus. selects sub-menus. scrolls backward through the menus. saves all entries. - 14 - HDTV 1000 T / HDTV 1001 T...
  • Page 15: Programming

    Preparation Test the software versions of the head-end station and the cassette and up- date them if necessary. The current software versions can be found on the website ”www.gss.de”. station. cassette (page 23) and adjust the TV test receiver to this channel / frequency.
  • Page 16: Programming Procedure

    Page 18 Bx  4 LINE Line  A  /  Line  B Line  A  <=   =>  Line  B Bx  4A OUTPUT Channel Channel  /  Freq. Bx  4A OUTPUT 850.00MHz on  /  off - 16 - HDTV 1000 T / HDTV 1001 T...
  • Page 17 C1/2 … C7/8 C7/8 G1/32 2 … 8k G1/4 … G 1/32 Bx 4A COFDM TPS ◀ ▶ 0x0000 … 0xFFFF CELL 0x0000 on / off - 17 - HDTV 1000 T / HDTV 1001 T Bx 4A STUFFING 34363 (32502)
  • Page 18 0x0000 –> 0000 on / off Page 16 auf Werkseinstellung Bx 4A FACTORY Bx 4A FACTORY zurücksetzen und speichern ▶ reset to factory defaults Defaults => STORE => M and store - 18 - HDTV 1000 T / HDTV 1001 T...
  • Page 19: Channel Strip "A" With Ca Module

    *)   Die  angezeigte  Information  ist   nächster  Service   abhängig  vom  verwendeten next  service   CA-­Modul.     The  information  displayed  is     dependent  on  the  CA  module   used. Page 17 - 19 - HDTV 1000 T / HDTV 1001 T...
  • Page 20: Programming The Cassette

    “Box 4” stands for slot 4 ”DVBS2-TPM” Type of cassette ”V 12” Software version of the cassette button. —> The “Selecting the input signal path” – “INROUTE” menu is activated. - 20 - HDTV 1000 T / HDTV 1001 T...
  • Page 21: Selecting The Input Signal Path

    (technical data) of the ASI component to be connected. buttons to place the cursor under the digits to be set for the transfer rate then use the buttons to set the transfer rate wished. - 21 - HDTV 1000 T / HDTV 1001 T...
  • Page 22: Setting The Asi Options

    —> Seting “burst” The data packets of the user data are spaced out evenly in the transport stream. button. —> The “Selecting the channel strip” – “LINE” menu is activated. - 22 - HDTV 1000 T / HDTV 1001 T...
  • Page 23: Selecting The Channel Strip

    Bx 4A OUTPUT Channel to select channel setting “Channel” or frequency setting “Freq.”. button. —> The “Setting the output channel” or “Setting the output frequency” – “OUTPUT” menu is activated. - 23 - HDTV 1000 T / HDTV 1001 T...
  • Page 24: Setting The Output Channel

    —> - - - of the channel or frequency display. off” use the on”. button. —> – LEVEL” menu is - 24 - HDTV 1000 T / HDTV 1001 T...
  • Page 25: Adjusting The Output Levels Of The Channel Strips

    LNB used. button. —> The “Setting the input symbol rate” – “SYMBOL” menu is activated. - 25 - HDTV 1000 T / HDTV 1001 T...
  • Page 26: Setting The Input Symbol Rate

    SYMBOL 27500 DVB-S button to place the cursor under “DVB-S” and set the required DVB-S2-mode with the buttons button. —> The “Setting the input frequency” – “FREQ” menu is activated. - 26 - HDTV 1000 T / HDTV 1001 T...
  • Page 27: Setting The Input Frequency

    At a value lower than “5” picture dropouts can occur. If “OK If a value < 5 is shown under the display changes from “OK” to “??”. In this case test the input signal. - 27 - HDTV 1000 T / HDTV 1001 T...
  • Page 28: Setting The Station Filter

    The figure of the menu below is dependent on the setting of the “Selecting the input signal path” menu (page 21). - 28 - HDTV 1000 T / HDTV 1001 T...
  • Page 29 ASI   TV   – 01/04 Filter .  .  .  .  . Bx  4B PROGRAM Filter on  /  off AUDIO Press the button. name and station type. play: “FILTER no Service”. - 29 - HDTV 1000 T / HDTV 1001 T...
  • Page 30 To save changes and to activate the station filters press the button. —> The display shows “PROGRAM Filter on”. inserted into the data stream and the PAT and SDT tables are updated. - 30 - HDTV 1000 T / HDTV 1001 T...
  • Page 31 Please take note of the tables below before setting the COFDM parameters. —> Programming the channel strip “A” with a CA module installed the set- tings for the CA module are activated (see page 43). - 31 - HDTV 1000 T / HDTV 1001 T...
  • Page 32: Cofdm Parameters

    16588 18431 19516 20107 17418 19353 20491 21112 14929 16588 17564 18096 19906 22118 23419 24128 64 QAM 22394 24882 26346 27144 24882 27647 29273 30160 26126 29029 30737 31668 - 32 - HDTV 1000 T / HDTV 1001 T...
  • Page 33 12441 13824 14637 15080 13063 14515 15369 15834 11197 12441 13173 13572 14929 16588 17564 18096 64 QAM 16796 18662 19760 20358 18662 20735 21995 22620 19595 21772 23053 23751 - 33 - HDTV 1000 T / HDTV 1001 T...
  • Page 34 Total symbol duration 373 336 317 308 767 672 634 616 1493 1344 1269 1232 [µs] Guard interval T [µs] 74.7 37.3 18.7 9.3 37.4 18.6 298.7 149.3 74.6 37.3 - 34 - HDTV 1000 T / HDTV 1001 T...
  • Page 35: Setting The Output Signal

    “NEG”. The default setting is “POS”. to place the cursor under “POS”. to set the spectral position to “NEG”. button. —> The “Setting the transmission parameters” – “COFDM-MODE” menu is activated. - 35 - HDTV 1000 T / HDTV 1001 T...
  • Page 36: Setting The Transmission Parameters

    Use the buttons to place the cursor under “G…”. buttons (“G1/4 G1/8 “G1/16 G1/32”). button. —> The “Setting the transmitter identification” – “COFDM TPS” menu is acti- vated. - 36 - HDTV 1000 T / HDTV 1001 T...
  • Page 37: Setting The Transmitter Identification

    ASI input signal cannot be measured. The ASI input signal therefore must be built in such a way so that the output data rate (“Number 1”) is not exceeded. - 37 - HDTV 1000 T / HDTV 1001 T...
  • Page 38: Setting A Substitute Signal In The Case Of An Incorrect Input Signal

    Bx 4A FAILURE Null Packets Use the buttons to set the output signal required. button. —> The “Setting the transport stream ID and the ORGNET-ID” – “TS/ONID” menu is activated. - 38 - HDTV 1000 T / HDTV 1001 T...
  • Page 39: Setting The Transport Stream Id And The Orgnet-Id

    COFDM cassettes. COFDM cassettes also add this new NIT. The status of all COFDM cassettes in the NIT menu changes to “on”. The display shows: “read … / copy …”. - 39 - HDTV 1000 T / HDTV 1001 T...
  • Page 40: Network/Operator Identification

    —> The menu display switches to “modified”. —> If you try to change the network/operator identification (operator ID) of not modified” appears in the display. button. —> The “Deleting a PID” – “DROP” menu is activated. - 40 - HDTV 1000 T / HDTV 1001 T...
  • Page 41: Deleting A Pid

    PID (“–> 0000”). button to set the cursor to “off” and rename the PID using the buttons (“on”). button. —> The “Factory reset” – “FACTORY Defaults” menu is activated. - 41 - HDTV 1000 T / HDTV 1001 T...
  • Page 42: Factory Reset

    – NIT is activated. “C” – Network/operator identification CAT is activated. —> By pressing the “Selecting the channel strip” without saving the programmed data (page 23). —> If necessary set channel strip “B”. - 42 - HDTV 1000 T / HDTV 1001 T...
  • Page 43: 5.4.1 Operation With A Ca Module

    —> In case of setting “scramble”: The “Setting the output signal” – “COFDM-MODE” menu is activated (page 35). —> In case of setting “descramble”: The “Setting the PID monitoring” – “CA” menu is activated. - 43 - HDTV 1000 T / HDTV 1001 T...
  • Page 44: Setting The Pid Monitoring

    —> The display shows e.g.: Bx 4A 01/03 MENU Information Meaning of the indicators: “Bx 4A A” “01/03” – The first of three menu items is activated. “MENU” – The menu of the CA module is activated. - 44 - HDTV 1000 T / HDTV 1001 T...
  • Page 45: Setting The Station Filter

    “TV” – TV channel type “X” – The currently selected station is to descramble. “04/09” – The 4th of 9 stations read is being displayed. “..” – Station name - 45 - HDTV 1000 T / HDTV 1001 T...
  • Page 46: Final Procedures

    EMC regulations securely. appropriate open-ended spanner. output level using the appropriate level controls or software dependent on the head-end station used. Please regard the assembly instructions of the respective head-end station. - 46 - HDTV 1000 T / HDTV 1001 T...
  • Page 47: Channel And Frequency Tables

    C 68 850.00 C 29 538.00 C 39 618.00 C 49 698.00 C 59 778.00 C 69 858.00 C 30 546.00 C 40 626.00 C 50 706.00 C 60 786.00 - 47 - HDTV 1000 T / HDTV 1001 T...
  • Page 48 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © GSS GmbH V12/14012010...
