Software • BIOS options

1.11.3 I/O address assignment

I/O address
000h -01Fh
020h - 03Fh
040h - 05Fh
060h - 06Fh
070h - 071h
080h
081h - 09Fh
0A0h - 0BFh
0C0h - 0DFh
0F0h - 0FFh
170h - 177h
1F0h - 1F7h
238h - 023F
278h - 27Fh
2E8h - 2EFh
2F8h - 2FFh
376h - 376h
378h - 37Fh
384h - 385h
3B0h - 3BBh
3BCh - 3BFh
3C0h - 3DFh
3E8h - 3EFh
3F6h - 3F6h
3F0h - 3F7h
3F8h - 3FFh
LPT1 + 400h
CF8h - CFBh
CFCh - CFFh
4100h - 417Fh
FF00h - FF07h
306
Resource
DMA controller 1
Interrupt controller 1
Timer
Keyboard controller
Real-time clock, NMI mask, CMOS
Debug port (POST code)
Page register - DMA controller
Interrupt controller 2
DMA controller 2
FPU
Secondary Hard Disk IDE channel
Primary Hard Disk IDE channel
COM5
Hardware Security Key (LPT2)
COM4
COM2
Secondary Hard Disk IDE channel
LPT1 (printer connection)
CAN controller
VGA controller
LPT3
VGA controller
COM3
Primary Hard Disk IDE channel
FDD controller
COM1
ECP Port, LPT+400h
PCI config address register
PCI config data register
MTCX
IDE bus master register
Table 151: I/O address assignment
Panel PC 700 with 945GME N270 CPU board User's Manual V 1.16
