Parts List - Linear Technology LT8390A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C4
6 1 C5
7 1 C6
5 2 C7, C8
8 1 C10
9 2 C12, C32
10 3 C14, C20, C45
16 2 D1, D2
25 1 L1
27 2 M1, M2
29 2 M3, M4
31 1 R1
32 1 R2
33 1 R3
34 2 R4, R6
35 1 R5
36 1 R7
37 1 R8
40 1 R11
45 1 U1
Optional Electrical Components
5 3 C37, C38, C44
11 0 C26, C34, C39
12 1 C27
13 0 C29, C30
14 0 C33, C40, C41, C42
15 2 C35, C36
17 1 D3
18 0 D4, D5
22 0 FB1, FB2, FB3, FB4, FB5, FB6 IND., OPTION, BEAD, FERRITE, 1206
26 0 L2
30 0 Q1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC2598A
PART DESCRIPTION
CAP ., 1μF, X7S, 100V, 10%, 0805
CAP ., 4.7μF, X5R, 10V, 10%, 0402
CAP ., 0.47μF, X5R, 16V, 10%, 0402
CAP ., 2200pF, X7R, 25V,1 0%, 0402
CAP ., 0.022μF, X7R, 25V, 10%, 0402
CAP ., 1μF, X7R, 25V, 10%, 0603
CAP ., 0.1μF, X7R, 25V, 10%, 0402
CAP ., 22μF, ALUM, 63V, 20%, SMD 6.3mm × 7.7mm
CAP ., 4.7μF, X7S, 100V, 20%, 1206
CAP ., 22μF, X5R, 25V, 10%, 1206
DIODE, SCHOTTKY, 100V, 250mA, SOD-323F,
AEC-Q101
IND., 1μH, Power Shielded, 20%, 7.3A, 6mm × 5.5mm
XSTR., POWER MOSFET, 60V, 40A, TSDSON-8
XSTR., POWER MOSFET, 25V, 40A, TSDSON-8
RES., 0.005Ω, ±1%, 1.5W, 3216, AEC-Q200
RES., 0.01Ω, 1%, 3/4W, 1206, SENSE
RES., 59k, 1%, 1/16W, 0402, AEC-Q200
RES., 10k, 1%, 1/16W, 0402
RES., 110k, 1%, 1/16W, 0402
RES., 383k, 1%, 1/16W, 0402, AEC-Q200
RES., 165k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402
IC, 2MHz SYN. BUCK-BOOST CONTROLLER,
28-PIN QFN
CAP ., 0.1μF, X7R, 25V, 10%, 0402
CAP ., OPTION, 0402
CAP ., 1μF, X5R, 16V, 10%, 0402
CAP ., 0805, OPTION
CAP ., OPTION, 1206
CAP ., 0.1μF, X5R, 100V, 10%, 0402
DIODE, SCHOTTKY, 20V, 1A, SOD-323F
DIODE, OPTION, SCHOTTKY, SMD
IND., OPTION, XAL4020 SERIES
XSTR., OPTION, PPAK 1212-8
MANUFACTURER/PART NUMBER
TDK, C1005X5R1A475K050BC
TAIYO YUDEN, EMK105ABJ474KV-F
MURATA, GRM155R71E222KA01D
MURATA, GRM155R71E223KA61D
KEMET, C0603C105K3RACTU
AVX, 04023C104KAT2A
SUN ELECTRONIC INDUSTRIES CORP , 63CE22FS
AVX, 12061Z475MAT2A
MURATA, GRM31CR61E226KE15L
NXP SEMICONDUCTORS, BAT46WJ
WURTH ELEKTRONIK, 74437336010
INFINEON, BSZ065N06LS5ATMA1
INFINEON, BSZ031NE2LS5ATMA1
SUSUMU, KRL3216E-C-R005-F-T1
SUSUMU, KRL1632E-M-R010-F-T5
VISHAY, CRCW040259K0FKED
VISHAY, CRCW040210K0FKED
VISHAY, CRCW0402110KFKED
VISHAY, CRCW0402383KFKED
VISHAY, CRCW0402165KFKED
VISHAY, CRCW0402100KFKED
LINEAR TECH., LT8390AEUFD#TRPBF
AVX, 04023C104KAT2A
AVX, 0402YD105KAT2A
MURATA, GRM155R62A104KE14D
NXP SEMICONDUCTORS, PMEG2010EJ
