73 Mall Drive • Commack, NY 11725 • www.accu-scope.com • Phone (631) 864-1000 • Fax (631) 543-8900

Dual-View Front-to-Back Quick Assembly Diagram

Set up the Main Microscope -- EXCEPT for the Main Viewing Head and Eyepieces -- following the

instructions in the EXC-400 Microscope Series Manual. The Main Viewing Head and Eyepieces will be

mounted after the Front-to-Back LED pointer unit is mounted.

EXC-400 Microscope Series

SUPPLEMENTAL INSTRUCTIONS

1 LED pointer unit

2 Main Viewing Head & Eyepieces

3 Secondary Viewing Head & Eyepieces

Table of Contents

Do you have a question about the EXC-400 Series and is the answer not in the manual?

Page 1 73 Mall Drive • Commack, NY 11725 • www.accu-scope.com • Phone (631) 864-1000 • Fax (631) 543-8900 EXC-400 Microscope Series SUPPLEMENTAL INSTRUCTIONS Dual-View Front-to-Back Quick Assembly Diagram Set up the Main Microscope -- EXCEPT for the Main Viewing Head and Eyepieces -- following the instructions in the EXC-400 Microscope Series Manual.
Page 2 73 Mall Drive • Commack, NY 11725 • www.accu-scope.com • Phone (631) 864-1000 • Fax (631) 543-8900 EXC-400 Microscope Series SUPPLEMENTAL INSTRUCTIONS Dual-View Front-to-Back Detailed Set Up Set-up on a sturdy, level surface with a minimum space requirement of 30(d) x 20(w) inches for the front-to-back orientation.
Page 3 Operation Dual Observer Arrangement (The ABC is the direction of image observed in the eyepieces) Two Observers, Front-to-Back Orientation Pointer Controller Pointer Light Adjustment Knob (on left side of LED Pointer Unit) Orientation of observed image: Main Head View Second Head View Adjust the Pointer Brightness NOTE: If the pointer is not in the field of view, rotate the pointer controller to move the pointer to the center of...
