Box contents
1
2
3
6
5
10
8
9
1 Mounting Plate x 1
2 Packing pieces x 2
3 Slam Latch x 1
4 Strike Plate x 1
5 Panhead fixing bolt x 2
6 Countersunk fixing bolt x 3 (1 spare)
7 Spindles x 2 (30mm and 40mm)
8 Countersunk screws x 4 (for Slam Latch if fixing plate not used)
9 Countersunk wood screws x 2 (for Strike Plate if used)
10 Fixing bolts x 4 (Allen key provided)
Go Keyless. Go KitLock.
4
7
CODELOCKS LTD UK
Tel: +44 (0) 1635 239645
Fax: +44 (0) 1635 239644
sales@codelocks.co.uk
CODELOCKS INC US
Tel: +1 714 979 2900
Fax: +1 714 979 2902
sales@codelocks.us
KitLock is a Codelocks Ltd brand
Fitting
Instructions
Advertisement
Related Manuals for CODELOCKS KitLock Slam Latch
Summary of Contents for CODELOCKS KitLock Slam Latch
- Page 1 7 Spindles x 2 (30mm and 40mm) 8 Countersunk screws x 4 (for Slam Latch if fixing plate not used) 9 Countersunk wood screws x 2 (for Strike Plate if used) 10 Fixing bolts x 4 (Allen key provided) KitLock is a Codelocks Ltd brand...
- Page 2 Slam Latch fitting instructions 4. Cut pan head bolt for upper fixing hole and countersunk bolt for Special Notes lower fixing hole. Length of bolts should be the thickness of the door plus 10mm ( ”), or 1 to 2 break off sections. Cut the bolts at one of the cutting points to avoid damaging the thread.
