12 en | Description
3

Description

Thank you for choosing an Electro-Voice portable column system. Please take time to consult
the manual to understand all the features built into your EV system and fully utilize its
performance capabilities.
The EVOLVE portable column loudspeaker is a new entry and form factor in the Electro-Voice
portable sound portfolio. Designed to deliver an uncompromising combination of low-profile
aesthetics and superior audio performance, the EVOLVE sets a new standard for portable
columnar systems.
EVOLVE is designed to quickly and easily be transported and assembled. The compact design
of the subwoofer and convenient included carrying bag for the sub pole and column array
provide minimal resistance to getting excellent, professional sound anywhere you need it.
Installation is made easier via the symmetrical aluminum subwoofer pole with an integrated
wire assembly. The connection is secured by the magnetic assisted latching system, which
magnetically locks the sub pole in place.
The full-range column array and its six 2.8-inch drivers are directed using custom-designed
waveguides for consistent 120° coverage. The ported subwoofer enclosure houses a 10-inch
woofer that is supported by 15 mm wood for enhanced stiffness and acoustical performance.
The Class-D amplifier provides up to 1000 watts of output power: 500 watts to the subwoofer
and 500 watts to the column array. The input panel features EV's industry-leading
QuickSmartDSP interface—allowing intuitive navigation of system parameters via an LCD with
single-knob control—as well as multiple options for signal routing and inputs.
The new Electro-Voice QuickSmart Mobile application utilizes Bluetooth® Low Energy (BTLE)
technology for the wireless configuration, control, and monitoring of up to six EVOLVE
systems simultaneously. High-resolution Bluetooth® audio streaming adds convenience for
wireless music playback in breakout rooms, intermission, and musical accompaniment.
Bluetooth® is available in select countries.
Electro-Voice quality and testing procedures far exceed the industry norm to yield efficient
and effective electro-acoustic performance; this creates components that deliver an accurate,
linear response at the system's highest output levels. When applied to EVOLVE, this
engineering philosophy results in a system that brings a new sonic benchmark to the column
speaker segment, all packaged in a sleek and portable enclosure that blends into the
background in any application from a lounge to a wedding reception.
3.1

System features

–
–
–
–
2019-08 | 01 |
EV QuickSmart Mobile application: quickly and wirelessly configure, control, and monitor
up to six EVOLVE systems simultaneously, and receive immediate notification during
critical performance conditions. Bluetooth® connectivity is available in select countries.
High-quality Bluetooth® audio streaming for background music or musical
accompaniment. Bluetooth® connectivity is available in select countries.
Ultra-wide 120° horizontal coverage via custom-designed waveguides and array-formed
40° asymmetrical vertical coverage means all acoustical energy is directed towards both
sitting and standing audiences.
Ideal for portable applications. Light weight and intuitive assembly via the magnet
assisted sub pole make a quality performance easier than ever.
