Summary of Contents for Electro-Voice EVID Series

  • Page 1 Owner’s Manual...
  • Page 2: Table Of Contents

    Any hardware used to suspend a loudspeaker array that is not provided by/associated with Electro-Voice® is the responsibility of others. EVID...
  • Page 3: Product Description

    Product Description Welcome Important Features Thank you for purchasing EVID™ Series • Line-array enhanced coverage control loudspeakers. Read through this manual • Organic, unobtrusive shape to familiarize yourself with the features, • SAM™ (Strong-Arm-Mount™) system applications, and precautions before you for secure and reliable mounting use these products.
  • Page 4: Model Summary

    Product Description Model Summary Packing List (3.2, 4.2, 6.2) EVID™ 3.2 Listed and illustrated below are the parts included in each boxed pair of EVID™ Most compact of the EVID™ Series, the speakers. EVID™ 3.2 uses dual 3.5-inch LF drivers with a .75-inch titanium direct radiator tweeter to provide high-fidelity, full-range sound over an extremely wide coverage...
  • Page 5: Product Feature Identification

    Product Description EVID™ Product Family Product Feature Identification Illustrated below are the major compo- nents of the EVID™ Series full-range speakers. A. Shielded dual woofers B. Coherent Coverage Waveguide horn (4.2 and 6.2 only) C. Dual low-frequency ports " 5 - l l D.
  • Page 6: Tm ) System

    Product Description SAM™ (Strong-Arm- Step-by-Step Installation Mount™) System and Wiring (3.2, 4.2, 6.2) EVID™’s SAM™ system (Strong-Arm- Step 1: Mount the SAM™ Bracket Mount™) excels at meeting the four to the Wall requirements for mounting FGM/BGM The SAM™ bracket can be mounted on systems: simple, quick, versatile, and either side of the speaker, enabling reliable.
  • Page 7: Step 2: Select Wattage Tap (Models 4.2T And 6.2T Only)

    Product Description Step 2: Select Wattage Tap Step 3: Mount the Speaker to the (Models 4.2t and 6.2t Only) SAM™ Bracket Before mounting the speaker to the Attach the speaker to the SAM™ bracket bracket, select the proper wattage tap with the socket head bolt B, as shown in setting for your installation.
  • Page 8: Step 4 - Wire The Speaker

    Product Description Step 4: Attach the Wiring to the Step 5: Secure the Seismic Tab Terminal Connector and Wire the Connection Point Speaker The rear of the enclosure includes an eyebolt for connection to a seismic The 4-pin phoenix-style plug-in connector restraint.
  • Page 9: Packing List (12.1 Subwoofer)

    Product Description Packing List (12.1 Subwoofer) Product Feature Identification Below is the list of parts included with the The 12.1 subwoofer comes with a dual- EVID™ 12.1 subwoofer. The parts are mode mounting bracket that enables the illustrated in Figure 17. unit to be easily mounted at either a wall/ wall (corner) or on a wall/ceiling (midwall) junction.
  • Page 10: Step-By-Step Installation And Wiring

    Product Description Step-by-Step Installation Step 2: Install the Safety Line Using accepted safe rigging practices, and Wiring (12.1 secure one end of a suitable safety line Subwoofer) (use cable, not chain, which will rattle) to a Step 1: Mount the Bracket strong, secure point above the speaker, a point that can withstand the shock of the The mounting bracket can be installed two...
  • Page 11: Step 4: Mount The Speaker To The Bracket

    Product Description Even though the enclosure hangs from the from amplifier top clip, always install the lower one to secure against possible disengagement of the top clip. Straighten the EV® logo and press firmly at its center to seat it securely –...
  • Page 12: Step 5: Test System Operation

    Product Description Rigging cables Rungs L angle Ceiling tile Eyebolts This side towards wall Acoustic port Figure 25: Midwall Mounting Figure 26: Attach L-Angles to Speaker Mounting through a suspended Step 5: Test System Operation ceiling grid After all connections are made test the complete system operation.
  • Page 13: Uniform Limited Warranty

    (3) years from the date of original must deliver the product, prepaid, to purchase. Additional details are included in Electro-Voice® Service or to any of its the Uniform Limited Warranty statement. authorized service representatives, together with proof of purchase of the product in the form of a bill of sale or receipted invoice.
  • Page 14: Appendix A - Integrating The 12.1 Subwoofer

    Appendix A: Integrating the Subwoofer Installation Examples Using a Separate Amplifier The EVID™ Series is a product family with Channel for the 12.1 the flexibility to fit the requirements of In certain specialized applications, it may many different applications. Listed below be desirable to drive the subwoofer with a are some suggested combinations for separate amplifier channel.
  • Page 15: Appendix B - Painting The Speaker

    Appendix B: Painting the EVID Speakers The 12.1 subwoofer is a painted wood • Clean the cabinet, bracket and clips by enclosure which can easily be repainted. rubbing with a lightly dampened cloth. Painting Process Do not use abrasives such as sandpaper or steel wool.
  • Page 16: Appendix C: Troubleshooting Table

    Appendix C: Troubleshooting Table i f i l . s t l l a i f i l v i t . y r y f i f i l i f i l . ) r l e l n i l n i l n i l...
  • Page 17: Appendix D - Technical Specs

    Appendix D: Technical Specifications Specification 3.2/3.2t 4.2/4.2t Frequency Response 85 Hz-20 kHz 65 Hz-20 kHz (-10 dB) Power Handling 150 watts 200 watts Sensitivity 87 dB, 1 W/1 m 90 dB, 1 W/1 m Impedance 8 ohms 8 ohms Max SPL 104 dB 111 dB Horizontal Coverage...
  • Page 18: 6.2T; 12.1

    Appendix D: Technical Specifications Specification 6.2/6.2t 12.1 Frequency Response 62 Hz-20 kHz 40 Hz-140 Hz (-10 dB) Power Handling 300 watts 175/175 watts Sensitivity 95 dB, 1 W/1 m 100 dB, 1 W/1 m Impedance 8 ohms 8 ohms Max SPL 116 dB 122 dB Horizontal Coverage...
  • Page 19: Notes

    Notes EVID Owner’s Manual...
  • Page 20 U.S.A. and Canada only. For customer orders, contact the Customer Service department at 800/392-3497 Fax: 800/955-6831 12000 Portland Avenue South Europe, Africa and Middle East only. For customer orders, Burnsville, MN 55337 contact the Customer Service department at Phone: 952/884-4051 49 9421-706 0 Fax: 49 9421-706 265 For warranty information, contact the Service Repair department at: Fax: 952/884-0043...
