LTE/LTE-Advanced Multi-Channel
Reference Solution
Startup Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTE and is the answer not in the manual?

Questions and answers

Summary of Contents for Keysight Technologies LTE

  • Page 1 Startup Guide LTE/LTE-Advanced Multi-Channel Reference Solution Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more information, go to www.keysight.com.
  • Page 3: Safety Notices

    © Keysight Technologies, Inc. 2013, 2014 the furnishing, use, or performance of No part of this manual may be reproduced in If this product is not used as specified, the...
  • Page 4 safety issues. When the modules are in use mains. When connecting sources to switching or the like that, if not correctly performed or cards, install protective devices to limit fault adhered to, could result in damage to the and operation within the specified full tem- current and voltage to the card.
  • Page 5 To prevent electrical shock, disconnect the equipment is Class A suitable for professional use and is for use in electromagnetic envir- Keysight Technologies instrument from onments outside of the home. 급 기 기 ( 업 mains before cleaning. Use a dry cloth or 무...
  • Page 7: Table Of Contents

    Table of Contents MIMO Introduction Related Documentation Step 1: Unpack and Inspect the Modules Inspect for Damage Return an Instrument for Service Step 2: Verify Shipment Contents Step 3: Install the Modules Items You Will Need Recommended best practices to ensure proper and safe module operating conditions If Your Solution Contains a Keysight M9021A Cable Interface Module If Your Solution Contains a Keysight M9021A Cable Interface Module in Slot 1 Module Installation Process Overview...
  • Page 9: Mimo Introduction

    MIMO Demo Tool source code and the product drivers. If you ordered an assembled MIMO solution, go directly to Step 5 to finish installation and configuration. For more information on LTE/LTE-A Multi-Channel Systems see: Solution Brochure 5991-4684EN Configuration Guide 5991-4647EN Related Documentation The documentation associated with this solution is available at the respective product pages on keysight.com (go to Document Library >...
  • Page 10 M9037A PXIe Embedded Controller Startup Guide (optional) – see www.keysight.com/find/M9037A M9021A PCIe Cable Interface – optional (see www.keysight.com/find/M9021A) keysight M9021A PCIe Cable Interface Module Installation Guide Keysight MIMO Demo Tool keysight PXI MIMO Demo Program User Guide keysight PXI MIMO Demo Program Developer Guide LTE/LTE-A Multi-Channel Reference Solution...
  • Page 11: Step 1: Unpack And Inspect The Modules

    All component modules for an M9381A M9391A instrument are factory tested, aligned, calibrated and shipped as a "bundle". It is important that you maintain the bundle when installing modules or returning an instrument for repair. See explanation (page 32). 1. Review the warranty information shipped with your product. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 12: Step 2: Verify Shipment Contents

    Ensure proper chassis air flow is maintained Select a chassis that provides thermal protection if fans become inoperable or forced air cooling is obstructed Use slot blockers (Keysight model Y1212A, 5 per kit) and EMC filler panels in empty module slots to LTE/LTE-A Multi-Channel Reference Solution...
  • Page 13: If Your Solution Contains A Keysight M9021A Cable Interface Module

    Internet location. Verify that the M9021A switches S301 and S201 are in the correct position. Refer to the following figure for M9021A switch positions. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 14: If Your Solution Contains A Keysight M9021A Cable Interface Module In Slot

    Slide the module completely into the chassis. When you begin to feel resistance, push up on the handle to fully seat the module into the chassis. d. Tighten the module retaining screws and torque to 5 Lb-In (0.57 N-m). LTE/LTE-A Multi-Channel Reference Solution...
  • Page 15: Module Installation Process Overview

    5 Lb-In (0.57 N-m). Performance may suffer if the screws are not tightened properly. 8. Install filler panels and slot blockers after installing the modules. Missing filler panels or slot blockers may disrupt air cir- culation in the chassis. The left-most slot does not accept a slot blocker. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 16 (0.904 Nm). This will extend the life of often-used connector. 10. Cable the system according to the information on MIMO Instrument Connections (page 17). 11. Power up the PXI chassis. 12. If you are using a remote PC, reboot the PC host. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 17: Mimo Instrument Connections

    This cable can be used to direct an External Reference Cable, coaxial, BNC (male) - SMB into the M9300A Ref In connector. (female) 1200 mm 8120-5091 M9300A 100 MHz Out 1 to M9301A 100 MHz In Cable, coaxial, SMB (female) - SMB (female) 120 mm LTE/LTE-A Multi-Channel Reference Solution...
  • Page 18: Recommended Mimo Configurations

    For all MIMO configurations, the Keysight M9300A PXIe Frequency Reference should be installed in slot 10 (the timing slot). For all MIMO configurations, the Keysight M9300A PXIe Frequency Reference 100 MHz reference cables must be of equal length. The appropriate number of 8121-2175 cables are provided. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 19 Placing the M9391A VSAs (recommendation) Install the M9391A VSA instruments in the chassis with the Keysight M9036A/M9037A Embedded Con- troller, or in the chassis with an Keysight M9021A Cable Interface Module in both slots 1 and slot 2. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 20: Sharing The M9300A Frequency Reference

    2. Type the following string: ShareReferenceVisaSession=0 This configuration will retain control of the M9300A if you try to open a new configuration. If you connect a new configuration, that includes the same M9300A, you will see the following error: LTE/LTE-A Multi-Channel Reference Solution...
  • Page 21 If an existing instance of the SFP is connected to the reference module in a shared (default) mode, and you try to connect a second instance of the SFP to the same reference with ShareRe- ferenceVisaSession=0 Advanced Option, you will get the resource locked error shown above. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 22: 2X2 Mimo Configuration In A Single Pxie Chassis

    100 MHz Out 1 to M9301A 100 MHz In (slot 5) 100 MHz Out 2 to M9301A 100 MHz In (slot 7) 100 MHz Out 3 to M9301A 100 MHz In (slot 11) 100 MHz Out 4 to M9301A 100 MHz In (slot 18) LTE/LTE-A Multi-Channel Reference Solution...
  • Page 23: 3X3 Mimo Configuration In Two Pxie Chassis With External Controller

    100 MHz Out 2 to M9301A 100 MHz In (slot 7) 100 MHz Out 4 to M9301A 100 MHz In (slot 4) These configurations can be used for x2 or x3 source only or analyzer only configurations. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 24: 3X3 Mimo Configuration In Two Pxie Chassis With Embedded Controller

    100 MHz Out 2 to M9301A 100 MHz In (slot 7) 100 MHz Out 4 to M9301A 100 MHz In (slot 4) These configurations can be used for x2 or x3 source only or analyzer only configurations. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 25: 4X4 Mimo Configuration In Two Pxie Chassis With External Controller

    100 MHz Out 1 to M9301A 100 MHz In (slot 11) 100 MHz Out 2 to M9301A 100 MHz In (slot 7) 100 MHz Out 3 to M9301A 100 MHz In (slot 14) 100 MHz Out 4 to M9301A 100 MHz In (slot 4) LTE/LTE-A Multi-Channel Reference Solution...
  • Page 26 Step 3: Install the Modules These configurations can be used for x4 source only or analyzer only configurations. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 27: 4X4 Mimo Configuration In Two Pxie Chassis With Embedded Controller

    100 MHz Out 2 to M9301A 100 MHz In (slot 5) 100 MHz Out 3 to M9301A 100 MHz In (slot 14) 100 MHz Out 4 to M9301A 100 MHz In (slot 4) These configurations can be used for x4 source only or analyzer only configurations. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 28: Step 4: Install The Software

    As an alternative, copy the installer files to a computer, transfer the installer files to a USB flash drive, and install the software from the USB flash drive. A high-quality SMA (male) to SMA (male) cable at least 10 inches (25.4 cm) long LTE/LTE-A Multi-Channel Reference Solution...
  • Page 29: Software Installation Procedure

    ** If you install or upgrade theKeysight 89600 VSA Software after installing the M9391A drivers, you need to run the 89600 VSA Integration utility. Go to Start > All Programs > Keysight > M9391 > 89600 VSA Integration. 3. Cycle Power Make sure that both your chassis and PC are powered down before you connect them. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 30: Step 5: Redeem Your Software Licenses

    BEFORE you power up the PC. When you power down your chassis, shut down the PC BEFORE you power down the chassis. Step 5: Redeem Your Software Licenses The basic software required to operate your solution requires no license. This includes: LTE/LTE-A Multi-Channel Reference Solution...
  • Page 31: Step 6: Configure Your Mimo Solution And Verify Operability

    Trigger Configuration on Windows Startup. 3. Select Run Self-Test. 4. Select Run Sample Waveform. 5. Select Configure 89600. NOTE: To use this functionality, please restart as Administrator. You now see the waveform shown in the following figure. LTE/LTE-A Multi-Channel Reference Solution...
  • Page 32: Step 7: Installation Is Complete

    Addi- tionally, you may see this same information from the SFP by using Help > About. Step 7: Installation is Complete Now that you have completed the installation and validated operation, you can proceed to: LTE/LTE-A Multi-Channel Reference Solution...
  • Page 33: Api Overview

    (a Microsoft HTML Help .chm file) is also installed with the driver and the content is available from LabVIEW's Context Help window. In addition, you can directly access the chm file (AgM9391 LabVIEW_Help) from this Start menu location: Start > All Programs > Keysight > AgM9391 LabVIEW Help. LTE/LTE-A Multi-Channel Reference Solution...
