3) Assembly Overview

Fig 3.2
3.2.1) After tube of flip frame is inserted, use (1) M8 x 70mm bolt
and (1) Spacer to secure frame to leg in outer hole as shown.
3.2.2) Use M8 x 55mm bolt to secure frame to leg in inner hole
as shown
3.2.3) Ensure that bolts are fully tightened.
3.2.4) Repeat previous steps for other leg.
Fig 3.3
INSTALLATION GUIDE
Fig 3.1
3.1.1) Locate the pre-assembled legs and
pre-assembled flip frame sub-assembly
3.1.2) Locate the M8 x 70mm bolts, M8 x
55mm bolts , and Spacers
3.1.3) Slide the legs onto the flip frame so
that the top tab inserts inside the tube and
the bottom tab is outside of the bottom
face of the tube.
3.3.1) Lay the top face down on a non-marring surface.
3.3.2) Place the frame on the top with the black flip
mechanisms spaced evenly from the sides of the table.
3.3.3) Line up the holes in the flip mechanisms with the
pre-drilled holes in the work surface.
3.3.4) Attach the frame to the top with the included
wood screws.
3.3.5) Insert the included Cap Covers into the holes in
the flip mechanisms to cover the screws.
