RUSTA KAMADO Manual page 9

Assembly instructions
IMPORTANT - Remove any packaging before use, but retain the safety instructions and store the
Ensure that the lid is closed prior to assembly.
ASSEMBLY INSTRUCTION
1
2
Attach the four pre-threaded castor wheels
(2 and 3) to each of the four brackets (1)
by pushing them through the hole. Using
an adjustable spanner secure each castor
wheel with 1 x nut (B).
B
x 4
F x 4
Assembly instructions
STEP 1 - Attach the four pre-threaded castor wheels (2 & 3) to each of the four brackets (1) by p
2
through the hole. Using an adjustable spanner secure each castor wheel with 1x nut (B
1
1. To assemble the cart insert the two cross
pieces (4) into one of the four brackets (1)
from both the top and bottom.
2. Continue to insert the cross pieces (4)
into the other three brackets (1).
4
STEP 2 - To assemble the cart insert the two cross pieces (4) into one of the four br
2
B
1
4
F
1
9
