Technical data

Drive XQ

8 Technical data
Performance specifications and guarantee only in connection with original spare and replacement
parts!
8.1 Drive XQ
Supply voltage (from the welding machine)
Duty cycle DC at 40° C
60 %
100 %
Wire feed speed
Factory-installed roll equipment
Drive
Wire spool diameter
Welding torch connection
protection classification
Ambient temperature
EMC class
Safety marking
Standards used
Dimensions
Weight
[1]
Load cycle: 10 min. (60 % DC ≙ 6 min. welding, 4 min. pause)
[2]
Ambient temperature dependent on coolant! Observe coolant temperature range!
44
[1]
[2]
42 VAC
600 A
470 A
0,5 m/min to 25 m/min
1,0-1,2 mm (for steel wire)
4 rollers (37 mm)
Standardised wire spools up to 300 mm
Euro torch connector
IP 23
-25 °C to +40 °C
A
/
See declaration of conformity (appliance
documents)
660 x 280 x 380 mm
26.0 x 11.0 x 15.0 inch
15,0 kg
33.1 lb.
