AXIS T92E Housing Series
NO TICE TICE
NO NO TICE
Mount the power connector after the power cable is pushed through the cable gasket.
5. If connecting an auxiliary device, for example an I/O, audio, or external power device, to
the camera, repeat the steps above as applicable to the specific device.
6. Put the bottom cover on the wall mount and tighten the screws (torque 2 Nm).

Install the Camera in the Housing

1. Loosen the holder screws and washers to remove the holder.
2. Secure the camera to the holder with the screws according to the illustrations and table
below. Tighten the stabilizing screw just lightly and tighten the camera screw to 2 Nm.
Be careful not to overtighten the screws
Camera model
AXIS T92E05/AXIS T92E20
Holder position and fasteners
AXIS T92E20
I/O cable
No
Yes
14
Cold Startup Delay
Off (0)
Off (0)
