AXIS T92E Housing Series

LED Indicators

Note
The housing LED referred to in the table below is located in the housing.
Housing LED
(fan and heater)
Green
Flashing green

Specifications

Item
Function/group
Models
General Casing
Operating conditions
Approvals
Dimensions (HxWxD)
Indication
Normal operation.
Single flash: Heater error
Double flash: Fan error
Triple flash: General error
Alarm events will be triggered through the camera's input port.
Contact your Axis reseller for information about spare parts and
troubleshooting.
10
Specification
AXIS T92E05 Protective Housing
AXIS T92E20 Outdoor Housing
Aluminium casing, polycarbonate
sunshield and cable cover. IP66- and
NEMA 4X-rated, IK10 impact-resistant
aluminum enclosure
AXIS T92E05: -20°C to 55°C (-4°F
1
to131°F)
Humidity 15 – 100% (condensing)
AXIS T92E20: -40°C to 50°C (-40°F
1
to122°F)
Humidity 15 – 100% (condensing)
AXIS T92E05: IEC 60068-2-6, IEC
60068-2-27 AXIS T92E20: EN
55022 Class B, EN 61000-3-2, EN
61000-3-3, EN 55024, EN 61000-6-1,
EN 61000-6-2, EN 60950-22, IEC
60068-2-6, IEC 60068-2-27, FCC Part
15, Subpart B, Class B, VCCI, Class B
ITE, C-tick AS/NZS CISPR 22, ICES-003,
Class B, KCC Class B
120 x 161 x 404 mm (4.7" x 6.4" x 15.9")
