L.B. White TS080 Owner's Manual And Instructions

Circulating tent heaters
Hide thumbs Also See for TS080:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
TS170
L.B.WH
WHITE
ITE
®
W6636 L. B. White Rd., Onalaska, WI 54650
Owner's Manual and Instructions
TS080
Congratulations!
You have purchased the finest tent heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and welcome any
suggestions or comments you may have...call us, at 608-783-5691.
ATTENTION ALL USERS
This heater has been designed and developed specifically for use as a direct-fired
circulating heater for tent heating applications. The heater has been evaluated by
Advantica Certification Services and found to conform to essential health and safety
requirements as required by the Gas Appliance Directive, Low Voltage Directive, and
Electromagnetic directive. If you are considering using this product for any
application other than its intended use, then please contact your local agent, or
contact L. B. White Co., Inc. in the U.S.A. at 608-783-5691.
W6636 L.B. White Rd., Onalaska, WI USA
Circulating Tent Heaters
MODELS
OUTPUT
TS080
23.4 KW
TS170
49.8 KW
(608) 783-5691
Fax: (608) 783-6115
(800) 345-7200
(608) 783-5691
FUEL
Both Models are
available in
either L.P. Gas
Vapor Withdrawal
or Natural Gas
Configurations.
Fax (608) 783-6115
150-21205-A

Advertisement

Table of Contents
loading

Related Manuals for L.B. White TS080

Summary of Contents for L.B. White TS080

  • Page 1 Your new L.B. White heater incorporates the benefits from the most experienced manufacturer of heating products using state-of-the-art technology. We, at L.B. White, thank you for your confidence in our products and welcome any suggestions or comments you may have...call us, at 608-783-5691.
  • Page 2 Save this Owner’s Manual for future use and reference. Owner’s Manuals and replacement labels are available at no charge. For assistance, contact L.B. White at 608-783-5691. WARNING Proper gas supply pressure must be provided to the inlet of the heater.

  • Page 3: Table Of Contents

    Parts Schematic TS080 ........

  • Page 4: Heater Specifications

    Heater Specifications Model TS080 TS170 Specifications L.P. Natural L.P. Natural Fuel Maximum Input 23.5 KW 49.8 KW Ventilation Air Required 950 Cubic Meters 2,050 Cubic Meters to Support Combustion per Hour per Hour Inlet Gas Supply MAX. Pressure Acceptable mbar...

  • Page 5: Fuel Information For Country Of Destination

    FUEL INFORMATION FOR COUNTRY OF DESTINATION Appliance Supply Gas Rate Type Category Pressure TS080 TS170 L.P. Gas 37 mbar 1.68 kg/hr. 3.55 kg/hr. Great Britain Nat. Gas 20 mbar 2.34 m /hr. 4.74 m /hr. L.P. Gas 50 mbar 1.68 kg/hr 3.55 kg/hr.

  • Page 6: Safety Precautions

    Safety Precautions WARNING Asphyxiation Hazard This heater is intended for heating of tents with Refer to the specification section of the heater’s temporary human occupancy. Do not use this heater Owner’s Manual, heater dataplate, or contact the L.B. for heating human living quarters. White Company to determine combustion air ventilation requirements of the heater.
  • Page 7 2. All installations and applications of L.B. White heaters the power cord. Failure to use a properly grounded must meet all relevant local, regional and national electrical supply can result in electrical shock, codes.

  • Page 8: Installation Instructions

    Installation Instructions GENERAL operation. If the heater is installed outside, it must WARNING be installed above any pooled or standing water. If Fire and Explosion Hazard the heater is located on the ground, a surrounding Can cause proper damage, severe injury or death. trench is recommended to drain any rain, ice or snow away from the heater.
  • Page 9 If you are in doubt, contact your local threaded areas and proper application of pipe agent or the L.B. White Co., Inc. compound before further tightening. Further tighten the gas connection as necessary to stop the leak. If 19.

  • Page 10: Heater Sizing Guidelines

    5. (D) ÷ 1,000 = Heat Requirements in KW. 4. 4190 (B) x 20 (C) ÷ 2 = 41,900 Watts (D). 5. (D) 41,900 ÷ 1,000 = 41.9 KW. Use one TS170 or two TS080 heaters. CYLINDER SELECTION Once you have determined the total heat requirement, you can now calculate how many 47 KG cylinder(s) are needed at the job.

  • Page 11: Wheel Assembly Model Ts170

    WHEEL ASSEMBLY MODEL TS170 1. Tap one retaining cap onto one end of the axle with a FIG. 1. hammer. RETAINING 2. Slide the wheel onto the axle, making sure the slots on the wheel are toward retaining cap. WHEEL 3.

  • Page 12: Regulator Storage Bracket Assembly Model Ts170

    REGULATOR STORAGE BRACKET ASSEMBLY MODEL TS170 Mount the storage bracket to the back of the case at the FIG. 4 two 3 mm holes using two 6.3 mm hex head sheet metal screws provided. Tighten both screws securely. HEATER CASE SIDE MOUNTING HOLES REGULATOR...

  • Page 13: Duct Installation (Optional Accessory)

    DUCT INSTALLATION 1. Mount the duct to the heater by inserting the tabs on FIG. 6 the duct adapter into the vertical slots on each side of the blower outlet. 2. Push down on the duct adapter to secure the adapter SLOTS in place to the heater.

  • Page 14: Start-Up Instructions

    Start-Up Instructions Follow steps 1 - 8 on initial start-up after heater installation 5. This heater includes a direct spark ignition (DSI) by a qualified gas heater service person. For normal start- control module for purposes of controlling the timing up, simply turn thermostat above room temperature.

  • Page 15: Cleaning Instructions

    Cleaning Instructions WARNING Fire, Burn, and Explosion Hazard This heater contains electrical and mechanical components in the gas management, safety and airflow systems. Such components may become inoperative or fail due to dust, dirt, wear, and aging. Periodic cleaning and inspection as well as proper maintenance are essential to avoid serious injury or property damage.

  • Page 16: Service Instructions

    Service Instructions MOTOR AND FAN WHEEL ASSEMBLY 1. Shut off the gas supply to the heater. NOTES: a. Fan wheel to motor mount plate spacing must be adjusted to a clearance of 4 mm 2. Disconnect the heater from its electrical supply. before tightening the fan wheel to the motor shaft.

  • Page 17: Gas Control Valve

    GAS CONTROL VALVE WARNING g. When heater lights, the gas gauge will read 25 Fire and Explosion Hazard mbar for LP vapor or 10 mbar for natural gas pressure. This pressure is the flowing gas Do not disassemble the gas control valve. pressure necessary for the heater to deliver its maximum output.

  • Page 18: Igniter

    IGNITER 1. Shut off the gas supply to the heater. FIG. 12 ELECTRODE GAP IS 3 MM AND 2. Disconnect the heater from its electrical supply. CENTERED OVER BURNER PORT 3. Open the burner end access panel. 4. The igniter and sensor assembly is located at the top of the burner casting mounted on a bracket.

  • Page 19: Troubleshooting Guide

    Troubleshooting Guide READ THIS ENTIRE SECTION BEFORE Ignition Control Lock-Out BEGINNING TO TROUBLESHOOT PROBLEMS. For safety, the ignition control in this heater continually monitors air proving components (fan motor and air WARNING proving switch) and burner flame. Electrical Shock and Burn Hazard The ignition control will lock out the control system if it does not recognize burner flame presence or if air Troubleshooting this system may require operating the...
  • Page 20 Heating Mode Problems Page DIRECT IGNITION OPERATION SEQUENCE: L.E.D. is not on, but heater is operating properly — Line Voltage is Sent to Selector Switch during a call for heat ......21 —...

  • Page 21: Is Not On, But Heater Is Operating Properly During A Call For Heat

    HEATING MODE LED Flashing Normal Operation LED is Not On, But Heater is Operating Properly During a Call for Heat. Defective LED in Control Module. Replace Ignition Control Module. LED is Steady On. No Flash Pattern. Reset Ignition Control Module: Ignition Control Lock-Out Due to: (A) Ignition Control Module Failure.

  • Page 22: Light Is Not On During A Call For Heat. Fan Motor Does Not Run, Heater Does Not Light

    Problem Proper Selector Voltage Supplied Selector Is Heater Switch Defective? LED Light to Heater Power Cord Replace Selector Switch Switch Set to Plugged In? Check for and Through Not On “Heat”? Continuity. Power During a Cord? Call for Heat. Fan Motor Check Dataplate for Does Not Move the...

  • Page 23: Two Times

    Problem LED Flashing If High Limit Switches are Tripped, Reset the You Have a High Limit Has Heater Proper Gas Switch(es) and Proper Fuel Sufficient Fuel Switches Tripped? Two Times Pressure Supplied Been Properly Supplied to Heater Supply Connected Determine Cause of Perform Continuity Indicates Burner at Heater...

  • Page 24: Three Times

    Is Air Proving Repair. Switch Arm Is Air- Proving Switch Binding? Three Times Stuck Open or Shorted? (Perform Indicates Lack of Continuity Air Proving in Fan Check.) Section of Unit. Replace Air-Proving Switch Assembly. Is Fan Wheel Binding? Repair or Replace Is Fan Wheel Tighten Fan Wheel Set Screw(s) to Loose On Motor...

  • Page 25: Five Times

    Ignition Control Sending Voltage to Gas Five Times Replace Ignition Control Module. Control Valve Before Burner Flame an Ignition Trial? is Sensed Before Ignition Trial Occurs. Gas Leaking Through the Gas Replace Gas Control Valve. Control Valve? IMPORTANT NOTES: With any electrical problem, all wiring should be checked for good connections and proper voltage. To determine if part is defective, place a jumper wire across the two terminals that the wires are connected to.

  • Page 26: Ventilation Mode Problems

    VENTILATION MODE Problem Proper Voltage Selector Proper Voltage Motor Does Is Heater Supplied to Selector Supplied from Replace Motor Switch Set to Not Run Plugged In? Switch from Power Selector Switch “Vent”? Cord? to Motor? Plug heater in. Replace Check all Electrical Move the Connections.

  • Page 27: Electrical Connection And Ladder Diagram

    Electrical Connection and Ladder Diagram CAUTION Always refer to the heater’s electrical connection diagram when servicing to avoid wiring errors and heater malfunction. Check for proper operation after servicing. WARNING: THIS HEATER MAY START AT ANY TIME GAS CONTROL DIRECT SENSE IGNITER GREEN/ BURNER HIGH LIMIT...

  • Page 28: Heater Component Function

    Heater Component Function Air Proving Switch with Paddle Heat Chamber Safety device used to insure that the proper air flow is being Metal “fire box” within the appliance that provides an area achieved before the gas valve is opened. where burner flame mixes with combustion air thereby providing heat.

  • Page 29: Parts Identification

    Parts Identification PARTS SCHEMATIC TS080...

  • Page 30: Parts List Ts080

    PARTS LIST TS080 Item Description Part Number Regulator (L.P. Gas) 23041 Regulator (Natural Gas) 23043 Hose Kit, 3m x 12.7mm ID, w/ Hose Adapter and Elbow 23040 Adapter 80858 Elbow 23039 Adapter, 1/2 NPT x 1/2 BSPT 80860 Bumper, Recessed, Heater Base...

  • Page 31: Parts Schematic Ts170

    PARTS SCHEMATIC TS170...

  • Page 32: Parts List Ts170

    PARTS LIST TS170 Item Description Part Number Regulator (L.P. Gas) 23042 Regulator (Natural Gas) 23043 Hose, 3m x 12.7mm ID, w/ Hose Adapter and Elbow 23040 Adapter 80858 Elbow 23039 Adapter, 1/2 NPT x 1/2 BSPT 80860 Bracket, Leg, “U” Channel 20750 Hub Cap 07187...

  • Page 33: Label Identification

    LABEL IDENTIFICATION Part Number TS080 TS170 Description Location L.P. Gas Natural Gas L.P. Gas Natural Gas Label, Wiring Diagram Interior Door, Burner End 21122 Label, Troubleshooting Label Interior Door, Burner End 21123 Nameplate Exterior Door, Burner End 21200 21199 21143...

  • Page 34: Fastener Selection Table

    L.B. White Co., Inc. will at its option, repair qualification. If neither is available, the warranty period will be 12 months from date of shipment from L B.
  • Page 35 Directive, Annex I and Annex II, and Low Voltage Directive, Annex 1 on the basis of type evaluation of design and manufacture. Designated Equipment: Model TS170 and TS080 Tent Heaters. Direct fired, gaseous fueled heaters, with optional ducting and air diffusers, for providing heat for temporary tent style facilities.
