Owner's Manual and Instructions
Tradesman Construction Heaters
MODELS
OUTPUT (BTUH)
FUEL
Propane Vapor
CP400
400,000
Withdrawal
Certification by:
Congratulations!
You have purchased the finest portable forced air construction heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and welcome any
suggestions or comments you may have...call us, toll-free, at (800) 345-7200.
ATTENTION ALL USERS
This heater has been tested and evaluated by C.S.A. International in accordance with
the requirements of Standard ANSI Z83.7 CSA 2.14 and is listed and approved as a
direct gas-fired forced-air construction heater with application for the temporary
heating of buildings under construction, alteration, or repair. If you are considering
using this product for any application other than its intended use, then please
contact your fuel gas supplier, or the L.B. White Co., Inc.
150-20530-F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for L.B. White CP400

Summary of Contents for L.B. White CP400

  • Page 1 Your new L.B. White heater incorporates the benefits from the most experienced manufacturer of heating products using state-of-the-art technology. We, at L.B. White, thank you for your confidence in our products and welcome any suggestions or comments you may have...call us, toll-free, at (800) 345-7200.
  • Page 3 Save this Owner’s Manual for future use and reference. ■ Owner’s Manuals and replacement labels are available at no charge. For assistance, contact L.B. White at 800-345-7200. WARNING ■ Proper gas supply pressure must be provided to the inlet of the heater.

  • Page 4: Table Of Contents

    Have your qualified installer review this manual with you so that you fully understand the heater and how it The L.B. White Co., Inc. has a policy of continuous product functions. improvement. It reserves the right to change specifications...

  • Page 5: Heater Specifications

    Heater Specifications Model SPECIFICATIONS CP400 Propane Fuel Type Maximum Input (BTUH) 400,000 Ventilation Air Required 1,582 CFM to Support Combustion Burner Manifold Pressure 4 PSI nlet Gas Supply MAX. 4 PSI Pressure Acceptable at the Inlet of the Heater for Purpose of Input MIN.

  • Page 6: Safety Precautions

    Safety Precautions WARNING Asphyxiation Hazard ■ Do not use this heater for heating human living Owner’s Manual, heater dataplate, or contact the L.B. quarters. White Company to determine combustion air ventilation requirements of the heater. ■ Do not use in unventilated areas. ■...
  • Page 7 Commonwealth of Massachusetts. least annually. 2. All installations and applications of L.B. White heaters 12. Always turn off the gas supply to the heater if the must meet all relevant local, state and national heater is not going to be used in the heating of the codes.

  • Page 8: Installation And Assembly Instructions

    ■ dataplate at all times. Contact your gas supplier, or Do not use open flame (matches, torches, candles, the L.B. White Co., Inc. if you have any questions. etc.) in checking for gas leaks. ■ Use only approved leak detectors.

  • Page 9: Propane Gas Supply Sizing

    13. The heater must be installed so as not to interfere 16. Take time to understand how to operate and with or obstruct normal exits, emergency exits, doors maintain the heater by using this Owner’s Manual. and walkways. Make sure you know how to shut off the gas supply to the building and also to the individual heater.

  • Page 10: Hose And Regulator Assembly

    HOSE AND REGULATOR ASSEMBLY 1. Connect rigid end of hose to gas inlet at heater and 2. Thread hose adapter to regulator outlet. Connect end tighten securely. See Fig.2. of hose with swivel nut to hose adapter. Tighten both securely. See Fig 3. FIG.

  • Page 11: Start-Up Instructions

    Start-Up Instructions 1. Connect electrical cord to an approved electrical ■ It is normal for air to be trapped in gas hose on new outlet. installations. You may need to recycle the heater before air is finally purged from the line and ignition 2.

  • Page 12: Cleaning Instructions

    2. Have your gas supplier check all gas piping annually damaged markings must be replaced immediately by for leaks or restrictions in gas lines. contacting the L.B. White Co., Inc. Dataplates, start- up and shut-down instructions and warnings are 3. Regulators must be periodically inspected to make available at no cost.

  • Page 13: Service Instructions

    Service Instructions GENERAL 4. The auto reset backflash, ON/OFF switch, and WARNING thermostat can be tested by jumpering the suspect Burn Hazard ■ part out of the electrical circuit.: Heater surfaces are hot for a period of time after the heater has been shut down.

  • Page 14: Air Proving Switch

    AIR PROVING SWITCH Remove fan blade from motor if necessary. FIG. 6 2. Remove screw securing switch assembly to bottom barrel of heater. Rotate the switch so its paddle can be pulled down through the hole. See Fig.6. 3. When installing the replacement switch, ensure SCREW mounting bracket’s tab is positioned in hole adjacent to mounting screw hole.

  • Page 15: Igniter

    IGNITER The tip of the igniter is exposed to a harsh environment Remove the igniter mounting screw and nut. When consisting of high temperatures and combustion products. replacing, ensure ignitor is positioned as shown in Periodic servicing is required. Fig.10, and its gap is set to 3/16 inch. See Fig. 11. FIG.

  • Page 16: Thermostat

    THERMOSTAT 1. Open the clip holding the thermostat bulb to the fan Unlock the bushing at the thermostat bulb’s access guard. Remove bulb from fan guard and fan guard hole at the barrel bottom. See Fig. 16. Guide the from heater. bulb down through the hole.

  • Page 17: Gas Control Valve

    GAS CONTROL VALVE 1. Loosen the compression nut from the half-union 2. Remove the screws adjacent to the gas inlet of the fitting at the gas control valve outlet. See Fig. 18. heater. Lift the control assembly from the heater. The replacement control will include the fitting and FIG.

  • Page 18: Troubleshooting Information

    Troubleshooting Information READ THIS ENTIRE SECTION BEFORE BEGINNING Fan Does Not Run, Heater Does Not Light... . 22 Fan Runs, Heater Does Not Light ....23 TO TROUBLESHOOT PROBLEMS.

  • Page 26: Electrical Connection And Ladder Diagrams

    Electrical Connection and Ladder Diagrams TRADESMAN 400 TRADESMAN 400 ULTRA CAUTION - REFER TO THE HEATER'S ELECTRICAL CONNECTION DIAGRAM WHEN SERVICING CAUTION - REFER TO THE HEATER'S ELECTRICAL CONNECTION DIAGRAM WHEN SERVICING TO AVOID WIRING ERRORS & HEATER MALFUNCTION. CHECK FOR PROPER OPERATION AFTER SERVICING. TO AVOID WIRING ERRORS &...

  • Page 27: Heater Component Function

    Heater Component Function Air Proving Switch Gas Hose Safety device used to insure that the proper air flow is being Flexible connector used to convey gas from supply line in achieved before the gas valve is opened. building to heater. Back Flash Switch Heat Chamber Safety device wired into the control system which is used to...

  • Page 28: Parts Identification

    Parts Identification PARTS SCHEMATIC...

  • Page 29: Parts List

    PARTS LIST Part Number Tradesman 400 Tradesman 400 Item Description ULTRA Regulator with POL ---------------22315--------------- Hose, Fixed X Swivel, 3/8 in. x 10 ft. ---------------22128--------------- Adaptor, Hose ---------------21997--------------- Thermostat Knob ---------------22214--------------- Thermostat ---------------24676--------------- Power Cord ---------------05795--------------- Switch, ON/OFF ---------------03834--------------- Lens, L.E.D. 22299 Screw ---------------07288---------------...

  • Page 30: Warranty Policy

    12 months from date of shipment from L B. White. found to be defective, L.B. White Co., Inc. will at its option, repair or replace the defective part or heater, with a new part or heater, F.O.B., Onalaska, Wisconsin.
