Run and Test
After code compilation and flashing the device, perform the following steps:
1.
Run the code
2.
Suspend the code execution
3.
Watch the local structure variable lastReset (the elements lastReset.resetType and
lastReset.resetTrigger)
4.
Check whether the lastReset.resetType is set to 'application' reset and whether the
lastReset.resetTrigger is set to 'cb3'.
5.
Press button 'PORST'
6.
Perform steps
7.
Check whether the lastReset.resetType is set to 'warmpoweron' reset and whether
the lastReset.resetTrigger is set to 'porst'.
2019-10-17
1.
through
3.
Copyright © Infineon Technologies AG 2019. All rights reserved.
7
