Infineon IM393 Series Application Note

Hide thumbs

Table of Contents

Quick Links

AN2018-13

IM393 Application note

IM393 IPM Technical Description

About this document

Scope and purpose

The scope of this application note is to describe the IM393 product family and the basic requirements for

operating the products in a recommended mode. This includes integrated components, such as IGBT,

bootstrap functionality or gate drive IC, as well as the design of the necessary external circuitry, interfacing and

application use.

Intended audience

Power electronics engineers who want to design reliable and efficient motor drive application with IM393 IPM

family.
