Renault MASTER User Manual page 300

Towing: breakdown
1
only use:
– at the rear left, towing point 1.
– at the front, towing hitch 4 (from
the tool kit) and towing point 2.
These towing points may only be used
for pulling the vehicle, never for lifting it
either directly or indirectly.
rear towing point 1
5.40
(2/2)
front towing point 2
accessing towing hitch 4
Move the driver's seat forward and re-
cline the seatback so that tool kit 3 can
be removed.
access to front towing point 2
Unclip cover 5 by inserting a flat-blade
screwdriver or similar under the cover.
3
first screw in towing hitch 4 as far
as it will go by hand, then finish tight-
ening it fully using the wheelbrace
stored in tool kit 3.
When storing the tools,
ensure that they are cor-
rectly replaced in unit 3, in
their original positions and
store the unit under the driver's
seat. Do not leave the tools unse-
cured inside the vehicle as they may
come loose under braking.
2
4
5
