TransPorTing obJEcTs
c
Front-wheel drive, standard wheels
C = 1,110 mm.
Rear-wheel drive, standard wheels
C = 1,760 mm.
Rear-wheel drive, dual wheels
C = 1,753 mm.
(2/2)
3
Towing
fitting the towing ball
D
Position the ball within the range of
height D, which must be between 350
and 420 mm, with the vehicle laden.
Tighten bolts 3, observing a tightening
torque of 196 Nm (Newton metres).
Permissible nose weight, maxi-
mum permissible towing weight
with or without braking ➥ 6.5.
choice and fitting of towing
equipment
3
Maximum weight of towing equip-
ment: 26 kg
For fitting and conditions of use,
refer to the equipment's fitting in-
structions.
Please keep these instructions with
the rest of the vehicle documenta-
tion.
If the towbar ball obscures the regis-
tration plate or the rear fog lights, it
should be removed when not in use.
In all cases, comply with local leg-
islation.
3.33
