CUSTOmER SERvICE INFORmATION

If you should have trouble with any of the steps listed in this Operating Manual, or if you find a missing or a damaged part
in your kit or require additional information, please contact your regional distributor at the address below:
In North America:
Global Services
18480 Bandilier Circle
Fountain Valley, CA 92708
Phone: (714) 963-0329
Fax: (714) 964-6236
Email: service@globalhobby.net
XTM Racing guarantees this kit to be free from defects in both material and workmanship, at the date of purchase. This does
not cover any component parts damaged by use, misuse or modification. In no case shall XTM Racing's liability exceed the
original cost of the purchased kit.
In that XTM Racing has no control over the final assembly or material used for final assembly, no liability shall be assumed for any
damage resulting from the use by the user of the final user-assembled product. By the act of using the final user-assembled product,
the user accepts all resulting liability. For detailed warranty information, refer to page 59.
PrIor to oPErAtINg your NEw modEl, PlEAsE thoroughly rEAd ANd uNdErstANd thE INformAtIoN coNtAINEd
IN thE thIs oPErAtINg mANuAl. doINg so wIll ENsurE your succEss ANd ProvIdE thE grEAtEst ENjoymENt
of thIs Product.

SAFETY WARNINGS AND ImpORTANT INFORmATION

n General Warnings
Under no circumstances should you operate your model in crowds of people. Serious injury could result.
l
Never operate your model on busy streets or if there are cars around.
l
Do not use your model to chase pets or other animals.
l
The electronics in your model are not waterproof. Therefore, do not drive through water, wet grass, mud or snow.
l
Because your model is operated by radio control, it is important to make sure you always use fresh and/or fully charged batteries (if
l
using Ni-Cds or Ni-MHs). Never allow the batteries to run low or you could lose control of the model.
If your model becomes stuck, do not continue to apply power or damage can occur. Release the throttle and retrieve your model by hand.
l
To prevent excessive r.p.m.s from damaging your motor and/or drivetrain components, we suggest reducing power while in the air
l
during jumps.
n Brushless Power System Warnings and Information
Your X-Terminator 2e is fitted with an extremely powerful brushless power system. For your safety, please use caution at all times to
l
keep your hands, loose clothing, etc., away from any moving parts.
For your safety and the safety of others, prior to making any programming changes to the electronic speed controller using the included
l
ESC programming card, we strongly suggest removing the pinion gear from the motor. This will prevent any chance of a runaway model.
The tyres on your model will 'balloon' to a larger diameter when mounted on a high-speed model, such as the X-Terminator 2e. DO
l
NOT hold the model in the air and run it up to full throttle or tyre failure could occur. Check the tyres often to ensure that they're
securely glued onto the wheels.
After soldering connectors onto your batteries, and when plugging your batteries into the ESC, make sure to observe correct polarity.
l
This will ensure that when you plug the batteries into the ESC that you do not plug them in with reverse polarity. Plugging the batteries
in with reverse polarity will damage the ESC and possibly damage your batteries.
The power output of the brushless power system is dependent on the type and quality of the batteries and battery connectors that
l
you use. While the power system will provide good power using lower-quality batteries, to take full advantage of the power
available, we recommend the use of high-quality batteries and connectors. We provide high-quality gold-plated Bullet connectors on
your model. We recommend keeping these connectors and using the equivalent on your batteries.
In Europe:
Ripmax Ltd.
241 Green Street
Enfield, EN3 7SJ, U.K.
Phone: (0) 20 8282 7500
Fax: (0) 20 8282 7501
Email: xtm@ripmax.com
Page 3
Continued On Next Page
