Ariston NIMBUS M NET User Manual page 18

Display symbols:
- ( ) Summer / DHW settings
- ( ) Winter
- ( ) Only Winter / CH settings (where present)
- ( ) Cooling (where present)
- ( ) OFF, system off
- ( ) Time program
- ( ) Manual operation
- ( ) Desired room temperature
- ( Room temperature detected
- ( ) Desired room temperature override
- ( ) Outdoor temperature
- ( ) AUTO function enabled
- ( ) HOLIDAY function enabled
- ( ) Central heating active
- ( ) Domestic hot water active
- ( ) Error indication
- ( ) Menu
- ( ) System performance
- ( ) Screen setting
- ( ) Floor Heating
- ( ) Circulation pump
- ( ) Valvola deviatrice
- ( ST1) Under-fl oor heating system thermostat
- ( ) Anti-frost function
- ( ) Thermal Cleanse Function
- ( ) Confi gurable device
- ( ) Heat pump
- ( ) Heating element 1
- ( ) Heating element 2
- ( ) Heating element excluded
- ( ) Manual mode HC
- ( ) DHW comfort in period at a reduced rate
setpoint up to 40 ° C during the period
at the full rate
- ( ) BOOST mode
- ( ) Silent mode
- ( ) Special function
- ( ) Dehumidifi cation
(AP) Access Point confi guration
- ( ) Gateway connected to internet
- ( ) Gateway not connected to router
- ( ) Gateway connected to router but not
to the internet
- ( ) Software update in progress
18 / GB
1
Initial start-up
The fi rst time the Sensys system interface is connected,
the user is required to choose certain basic settings.
First, you will need to select the user interface language.
Turn the knob and select the desired language, then press
the OK button to confi rm. Move on to setting the date and
time. Turn the knob to make a selection, press the OK but-
ton to confi rm your selection, turn the knob to set the va-
lue. Press the OK button to confi rm.
Save the settings by pressing OK.
Press the OK button to access the Menu. Use the knob
in the centre to scroll through the menu list and select a
parameter, then press OK to confi rm.
NOTE
Some parameters are protected with an access code (sa-
fety code) which protects the boiler settings from unautho-
rised use.
Thank you for choosing Heat Pump compatible with Ari-
ston Net*, the service designed and manufactured by Ari-
ston, to provide a whole new experience in using a dome-
stic heating or cooling and water system.
Ariston Net allows you to start, stop and check the tempe-
rature of domestic heating or cooling and water anytime,
anywhere from a smartphone or PC. It allows you to con-
stantly monitor energy consumption to ensure you save
on your gas bill. It also notifi es you in real time if there
is a boiler failure. If a teleassistance service is activated,
the service centre will be able to solve problems remotely
where possible or arrange an appointment at your earliest
convenience.
*availability of the service must be verifi ed with your local Gas Safe registered engi-
neer. For more information call us on 0333 240 8777
OK
2 3 4
.
