C44
FIREPLACE
Installation Reference Guide
REFER TO OWNER'S MANUAL FOR SPECIFIC INSTALLATION REQUIREMENTS AND ADDITIONAL PRODUCT INSTRUCTIONS
Minimum

Framing Dimensions

Depth
20"
Width
55"
Header Height
38"
Enclosure Ceiling
65"
Note: Vent size 5/8

Clearance to Combustibles

A - Finishing edge to side wall
B - Minimum clearance to enclosure ceiling
C - Minimum clearance to mantel height
D - Front of door to edge of floor protection
E - Minimum alcove width
1"
(25mm)
Clearance from
framing studs
to venting
508 mm
1397 mm
965 mm
1651 mm
7"
65"
See Chart
0"
60"
S T E E L S T U D
65"
38"
(1651mm)
(965mm)
20"
(508mm)
229 mm
1651 mm
A
See Chart
0 mm
1524 mm
55"
(1397mm)
B
C
E
D
