PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
C Series
Cool Surface System
F R O N T V E N T [ 5 0 - 3 4 6 3 ]
INSTRUCTION MANUAL
This Cool Surface System has been tested for compliance to Standards:
ANSI Z21.88-2014 and CSA Z2.33-2014.
This Cool Surface System has been approved for use on the ENVIRO C34/44/60 Direct Vent
fireplaces only and must be installed at the time of fireplace installation.
The following instructions must be followed in conjunction with the fireplace installation
instructions to comply with the standards and allow safe operation of the installed fireplace.
4001609
1
50-3463
Version Française: www.enviro.com/fr.html
Advertisement
Related Manuals for Enviro C34
Summary of Contents for Enviro C34
- Page 1 This Cool Surface System has been tested for compliance to Standards: ANSI Z21.88-2014 and CSA Z2.33-2014. This Cool Surface System has been approved for use on the ENVIRO C34/44/60 Direct Vent fireplaces only and must be installed at the time of fireplace installation.
-
Page 2: General Information
Item Description Item Description out in the CSS. C34 Main Panel Trimable Deflector C44 Extension C60 Extension Figure 2. Cool Surface System Combustible Facing Kit - Parts Diagram... - Page 3 Dimensions 8 " (23.8 cm) 4 " (7 cm) Standoff 8 " 2 " (6.6 cm) Standoff (30.2 cm) 40" (101.6 cm) 2 " (8.9 cm) 45" (114.3 cm) 2 " (1.3 cm) 8 " (6.7 cm) 4 " (80.6 cm) 8 "...
-
Page 4: Framing And Clearances
CSS Outlet Min. Top and Bottom standoff = 2⅝” (6.7 cm) *All C Series* 45" (114 cm) 7 1/2" (2.5 cm) 2 x 4 (On Edge) 37 1/4" (94.6 cm) Min. Height Figure 5. C34 - CSS Framing & Rough Opening... - Page 5 Framing & Clearances QUALIFIED INSTALLERS ONLY C44 & C60 C60 = 71" (180 cm) C44 = 55" (140 cm) 45" (114 cm) Steel Stud - C60 Only 7 1/2" (2.5 cm) Steel Stud - C60 Only 37 1/4" (94.6 cm) Min.
- Page 6 Framing & Clearances QUALIFIED INSTALLERS ONLY inimum learances minimum vent Shown below in Figure 7 are the minimum framing and clearances for the CSS when the fireplace is installed with the minimum allowable vent length: Min. Ceiling Clearance from top of CSS outlet = 4” (10.2 cm) Min.
- Page 7 Framing & Clearances QUALIFIED INSTALLERS ONLY evised antel equirements Refer to Figure 8 for a combustible mantel installation, measurement is from bottom of the unit to the bottom of the mantel. If you are planning on installing a TV above the fireplace refer to page 10 to see the options available. Note: Minimum height of mantle if you intend on using a surround is 31”...
- Page 8 Framing & Clearances QUALIFIED INSTALLERS ONLY Min. Height to Ceiling 55-1/16” (1399cm) 12” (305mm) 8” (203mm) 4” (102mm) 33“ 2-1/16” (84cm) (75cm) 31 “ (79cm) Min. Height For Surround 29 “ (74cm) Figure 9. CSS - Min. Framing & Clearances...
- Page 9 Framing & Clearances QUALIFIED INSTALLERS ONLY inished pening Combustible wall material i.e. drywall, shiplap etc. is permitted around the outlet of the CSS with a 3/8” (.95 cm) air gap required around the outside perimeter of the outlet. This creates a finished opening approx.
-
Page 10: Installation
Installation Installation and service must be performed by a qualified installer, service agency or the gas supplier. tv i nstallation onsiderations If you are planning to mount a TV above your fireplace some considerations must be made to ensure it is protected from the heat. - Page 11 Installation QUALIFIED INSTALLERS ONLY ollars Prior to fireplace installation, the two supplied duct collars Outer Cover must be attached to the top of the fireplace as shown in Plate (x2) the steps below: Inner Cover Step 1: Using a T20 screwdriver, remove the inner and Plate (x2) outer cover plates from the fireplace as shown (Figure 14).
- Page 12 Installation QUALIFIED INSTALLERS ONLY urFace ystem ront Step 1: Frame in the rough opening for the CSS as shown in Figures 5 & 6 (Pages 4,5) in the desired location following all required clearances as stated in the F & C section.
- Page 13 The first notch on the far left will size it for a C44 and the second notch will size it for a C34. As shown ins Figure 20 Figure 20. Trimmable Deflector trim notches...
- Page 14 Step 2: All the Units use the C34 panel as a base. If installing a C44, use both the C34 and C44 panels. If installing a C60, use both the C34 and C60 panels. Once you have your required panels locate the flanges in the figure 21 below.
- Page 15 Step 5: If installing a C44 or C60, attach your extension piece to the C34 main panel. (Figure 24) Step 6: Remove the top cabinet T20 screws on the left and right side so that you can reuse them to fasten the Combustible Facing Kit asembly to the unit.
- Page 16 Installation QUALIFIED INSTALLERS ONLY ombustible acing ptional Before installing your chosen facing material, a 1/2” base layer must be placed over the framing up to the Combustible Facing Kit assembly as shown below. Up to a 1” thick material may be placed on top of the base layer and the combustible facing kit assembly afterwards.
-
Page 17: Replacement Parts
Replacement Parts Item Description Part Number CSS Instruction Manual 50-3481 Outlet Trim Bezel 50-3307 Vent Collars (Set of 2) 50-3309... - Page 18 Notes...
- Page 19 Learn more about our products at ƒ Detailed Product Lineup ƒ Model Photo Galleries ƒ Downloadable Manual PDF’s ƒ Unit Comparison Charts ƒ Youtube Burn Example Videos ƒ Online Brochures ƒ Dealer Locator Tool...
- Page 20 MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com October 10, 2017 C-15204...
