PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
C44
HEAT DISTRIBUTION / TV KIT
N A T U R A L L Y V E N T E D [ 5 0 - 3 2 1 3 ]
INSTRUCTION MANUAL
This Heat Distribution Kit has been tested for compliance to Standards:
ANSI Z21.88-2014 and CSA Z2.33-2014.
This Heat Distribution Kit has been approved for use on the ENVIRO C44 Direct Vent fireplace
only and must be installed at the time of fireplace installation.
The following instructions must be followed in conjunction with the fireplace installation
instructions to comply with the standards and allow safe operation of the installed fireplace.
4001609
50-3306
Version Française: www.enviro.com/fr.html
