C44I / C44ID
D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
C#4001609
CERTIFIED TO/CERTIFIÉ AUX: ANSI Z21.88 / CSA 2.33 / CSA 2.17
1
50-3282
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C44ID and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro C44ID

Summary of Contents for Enviro C44ID

  • Page 1 C44I / C44ID D I R E C T V E N T F I R E P L A C E - I P I OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the C44I / C44ID unit is pulled out of its installation, and A barrier designed to reduce the risk of burns from the the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2 Table of Contents �...

  • Page 5: Table Of Contents

    Table of Contents Outdoor Install: ........... 30 Flex Venting: .

  • Page 6: Codes And Approvals

    This appliance has been tested by INTERTEK and found to comply with the established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (C44I /C44ID ; NATURAL GAS, PROPANE GAS) TESTED AND LISTED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES...

  • Page 7: Specifications

    Specifications imensions 11 3 " " 231mm 284mm 19 15 17 13 " " 507mm 453mm 46 1 " " 1171mm 13mm 54 7 " 1394mm " 12" 186mm 307mm 16 1 38" 44" " 30 11 " 965mm 1117mm 410mm 779mm Electrical...

  • Page 8: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE� ighting nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

  • Page 9: Air Shutter (Venturi)

    Operating Instructions hutteR entuRi The air shutter plays a very important role in flame appearence and combustion quality. The shutter adjusts how much air gets mixed with the gas before it ignites. Adjustments can be made to accomodate various climates and vent configurations. To gain access to the air shutter remove the safety screen and intake shield.

  • Page 10: System Description

    Operating Instructions For C44ID models refer to the separate Dexen user manual supplied for remote control operations. ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and wiring harness to connect to the gas valve, stepper motor battery holder, and convection fan.

  • Page 11: Integrated Fireplace Controller (Ifc)

    Operating Instructions Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point Aux ON Temperature/Level/State Flame ON Split Flow Dimmer ON Comfort fan Figure 5: Proflame 2 Transmitter LCD Screen. (iFc): ntegRateD iRepLace ontRoLLeR The Proflame 2 IFC (Figure 6) connects directly to the gas valve, split flow valve, stepper motor, pilot and covection fan with a wiring harness.

  • Page 12: Operating Procedure

    Operating Instructions peRating RoceDuRe Initializing The System For The First Time Install the four (4) AA batteries into the IFC battery holder. Note the polarity of the battery and insert into the battery bay as indicated on the body of the battery holder. Press the reset button on the IFC marked “SW1” (see Figure 6). The IFC will “beep”...
  • Page 13 Operating Instructions Turn off the Appliance Room Temperature Press the ON/OFF Key on the Transmitter. The Transmitter LCD display will only show the room temperature and Icon (see Figure 9). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.
  • Page 14 Operating Instructions Top Light Control The firebox toplight can be controlled with the Transmitter. The light is non-adjustable but can be turned on and off as desired. To control the top light press the MODE key (Figure 4) to index to the AUX control icon (Figure 13).

  • Page 15: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. To remove the door (see page 17). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 16: Cleaning Decorative Surfaces

    Maintenance And Service Leaning ecoRatiVe uRFaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked/unwrapped carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints. It is important to note that fingerprints and other marks can leave a permanent stain on plated finishes.

  • Page 17: Maintenance And Service

    Maintenance And Service Lass emoVaL To remove the glass door use a 3/8 socket to remove the 4 upper bolts and rotate outward. To replace the door simply reverse the order; do not over tighten the bolts or they may strip. WARNING: Do not touch or attempt to remove the glass door if the fireplace is not completely...

  • Page 18: Access Panels

    Maintenance And Service ccess paneLs There are two access doors in the bottom on the firebox that is used for servicing components after the unit is installed in a construction enclosure. Proceed only when the unit has completely cooled down. 1.

  • Page 19: Fuel Conversion

    Maintenance And Service onVeRsion Kit Parts List for C44I Model: 1 - Orifice (NG - #32 DMS or LP - #49 DMS) 1 - Stepper regulator with hardware 1 - Installation instruction sheet 2 - Conversion labels 1 - Pilot Orifice (NG: 0.2) or (LP: 0.14) Carefully inspect all parts supplied with this conversion kit.
  • Page 20 Maintenance And Service the stepper regulator and the valve body. The new stepper regulator already has this diaphragm installed. c) Install the LP (or NG) stepper regulator, with the new longer T-20 screws included in the kit and connect the harness to the IFC.

  • Page 21: Initial Installation

    Initial Installation QUALIFIED INSTALLERS ONLY ntRoDuction This section of the owner’s manual is for the use of qualified technicians only. Fireplace placement, hearths, facing, mantels, and venting terminations will be covered, as well as the gas and electric systems. There are several installation safety guidelines that must be adhered to. Please carefully read the safety precautions at the front of this manual.

  • Page 22: Steel Stud

    Initial Installation QUALIFIED INSTALLERS ONLY teeL Framing of the fireplace requires a steel stud placed above the unit. The steel stud included with the fireplace comes in two pieces that combine to create a telescopic steel stud. This allows for horizontal adjustment to fit the specific length of your unit.

  • Page 23: Placement And Framing

    Initial Installation QUALIFIED INSTALLERS ONLY Lacement anD Raming 1” (25mm) Clearance from framing studs to venting S u p p l i e d S t e e l S t u d 65” 38” (1651mm) (965mm) 55” (1397mm) 20” (508mm) Figure 31: Construction Framing Dimensions Table 2: Framing Dimensions...

  • Page 24: Alternate Gas Inlet Location

    Initial Installation QUALIFIED INSTALLERS ONLY LteRnate nLet ocation The gas inlet location can be moved to the Remove bottom of the cabinet if needed. This may be needed for certain installations. First remove the two screws on the left side of the unit, see Figure 33.

  • Page 25: Floor Protection

    LooR Rotection The C44I / C44ID may be installed on a combustible floor. If the appliance is to be installed directly on carpeting, tile, or other combustible material other than wood flooring, the appliance must be installed on a metal or wood panel extending the full width and depth of the appliance.
  • Page 26 Initial Installation QUALIFIED INSTALLERS ONLY If adding a mantel to the C44I / C44ID please note the critical dimensions shown in Figure 35. These are minimum dimensions as per certification and must be followed. 9” Min [229mm] 39 1 Minimum "...

  • Page 27: Installation With Recess

    Initial Installation QUALIFIED INSTALLERS ONLY nstaLLation with ecess Refer to dimensions in Figure 36 if building a recess above the fireplace. Note the dimensions from the finishing edge to the stud below the recess finishing material. The vertical finishing material at the back of the recess must be be spaced 7/8”...

  • Page 28: Corner Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation The dimensions for installing a fireplace in the corner of a room are given in Figure 37. Refer to “I nstallatIon ” for allowable pipe lengths. llowaBle axIal onfIguratIons Do not interfere with the structural integrity of the walls. Shown below are minimum clearances; increasing these dimensions is allowable as long as vent length remains in the allowable range.

  • Page 29: Horizontal Vent Install

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL ent instaLL Figure 39 shows a horizontal vent installation with minimum clearances. The horizontal vent shield must be used when the minimum vent configuration is used. If more than 12” of vertical rise is used the shield should not be installed.

  • Page 30: Outdoor Install

    QUALIFIED INSTALLERS ONLY utDooR nstaLL All Enviro C-Series fireplaces may be installed in a covered outdoor area when following the requirements stated below: • Fireplace must be installed in a weather proof enclosure while still following all clearance to combustible materials as outlined in the fireplace’s manual.

  • Page 31: Flex Venting

    Use 5X8 Flex Adapter Kit [50-3789]: This kit will allow you to adapt co-axial flex to the fireplace, make your Any Enviro Approved vent run, then adapt back to rigid venting (flex not Rigid Venting included).

  • Page 32: Clearances & Non-Combustible

    There must be a minimum distance of 7” (229mm) from the finishing edge of the C44I / C44ID to an adjacent wall composed of combustible material.

  • Page 33: Tv Installation Considerations

    Initial Installation QUALIFIED INSTALLERS ONLY tV i nstaLLation onsiDeRations If you are planning to mount a TV above your fireplace some considerations must be made to ensure it is protected from the heat. A recess, mantel, or a combination of both will be needed in order to keep the heat away from the TV.

  • Page 34: Vent Termination Restrictions

    Only Approved Direct Vent may be used for installation of the C44I / C44ID� The minimum vent installation for the C44I / C44ID must include a 12” vertical section and 90° elbow before being horizontally vented. Maximum Vertical venting is 40’ (12.2 m). This model is vented with co-axial 5”...

  • Page 35: Venting Clearances

    Initial Installation QUALIFIED INSTALLERS ONLY 12 in (30 cm) 9 in (23 cm) Clearance to non-mechanical air supply inlet to building, or the combustion air inlet to any other appliance. 6 ft (1.83 m) 3 ft (91 cm) above if within 10 Clearance to mechanical air supply inlet.

  • Page 36: Approved Venting Parts

    Initial Installation QUALIFIED INSTALLERS ONLY ppRoVeD enting aRts This fireplace has been tested and certified Table 5: Approved Vent Manufacturers for use with the venting brand names liste Manufacturer Brand Name Nominal Sizes above in table 5. Refer to table 6 below for EXCELDirect 5”...

  • Page 37: Allowable Co-Axial Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe xiaL onFiguRations Figure 48 shows the range of venting options using either vertical or horizontal terminations; any layout that remains within the shaded area is acceptable. Having the fewest number of elbows is ideal as they tend to restrict air movement.
  • Page 38 Initial Installation QUALIFIED INSTALLERS ONLY If your C44I / C44ID has been 40’ (12.2m) converted using 50-3270 conversion this venting diagram. LP Vent Flame Appearence: Pin point on the map where your vent configuration will 35’ Position (10.7m) lay. Remember to consider elbows in the HORIZONTAL plane account for horizontal distance as stated on the previous page.

  • Page 39: Exhaust Restrictor Setting

    When installing the C44I / C44ID it may be necessary to add a restrictor in the firebox to control the combustion and flame appearance. The exhaust restrictor ring kit is included in the manual bag. To install the exhaust restrictor, the safety screen assembly and glass door must be removed, see the Maintenance and Service section [page 16 &...

  • Page 40: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination � A MINIMUM OF 12” [305mm] VERTICAL RISE PLUS AN ELBOW IS REQUIRED WHEN HORIZONTALLY TERMINATING WITH AN APPROVED VENT CAP� 2. Horizontal pipes must not be level� For every 12” (305 mm) of horizontal travel (away from stove),...

  • Page 41: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY Step 4. With the hole now framed, the wall thimble installed, and the pipe extending into the wall, proceed to the outside. Attach the termination to the pipe using RTV and Mil-Pac or Rutland No 78 Stove and Gasket Cement to seal joints.
  • Page 42 Initial Installation QUALIFIED INSTALLERS ONLY Step 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
  • Page 43 Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’ (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 55).

  • Page 44: Gas Line Connection And Testing

    Initial Installation QUALIFIED INSTALLERS ONLY onnection anD esting WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a 3/8”...

  • Page 45: Electrical Requirements

    If any of the original wire as supplied with the appliance must be replaced, it must be replaced with 18 AWG wire with a temperature rating of 105°C Proflame 2 System - Wiring Diagram Note: For C44ID specific wiring diagram refer to the Dexen user manual supplied and label attached to the fireplace. Transmitter - TMFLSA...
  • Page 46 Initial Installation QUALIFIED INSTALLERS ONLY The C44I / C44ID needs a hardwired power connection in order for the unit to operate. There is also a battery pack that takes four AA batteries in case there is a loss of power.
  • Page 47 Initial Installation QUALIFIED INSTALLERS ONLY Receptacle Inside Cabinet Incoming Power Green White Black Figure 60: C44I Fan Kit Wiring Diagram. See 50-4173 instruction manual for C44ID wiring diagram Receptacle Gray Gray Te on Inside Cabinet 3A Fuse Incoming Power Black...

  • Page 48: Secondary Installation

    Secondary Installation C44I / C44ID Light Kit (50-3211) The C44I / C44ID has an optional light kit that is wired into the IFC. The fireplace must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code Part 1, Safety Standards For Electrical Installations, or The National Electrical Code ANSI / NFPA 70 in the US..

  • Page 49: Panel And Media Installation

    Secondary Installation ezeL nstaLLation The unit comes with a set of burner bezels. There are two long bezels, one short, and one short with a notch cutout. 1. Remove the safety screen and glass door 2. Place the bezels directly onto the burner platform as shown in Figure 63. No fasteners are required. 3.
  • Page 50 Secondary Installation WARNING: Be sure there is no media in the protected pilot area of the burner pan. NO MEDIA IN THIS AREA Figure 66: Protected Pilot Area IMPORTANT: IF THE AIR SLOT AROUND THE BURNER IS BLOCKED WITH MEDIA THIS WILL CAUSE THE FIREPLACE NOT TO BURN PROPERLY.
  • Page 51 Secondary Installation Unwrap your new Enviro liner set from their protective packaging. Be careful not to scratch or bump then liners as they are fairly fragile. If the liners arrive damaged please contact your nearest Enviro dealer. 5. Remove the 3 liner retainers from inside the firebox using a T-20 Torx screwdriver. Then remove the existing steel liners starting with the sides first.

  • Page 52: Log Set Installation

    Secondary Installation nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. Using the pictures provided, carefully set the logs in place. NOTE: The logs are fragile and should be handled gently.
  • Page 53 Secondary Installation 4. Position the front right log as shown. the end will butt up to the right liner as well as the log in the rear. Align the front right log with the firebox edge as shown below. 5. Position the eighth log as shown below.

  • Page 54: Trouble Shooting

    Trouble Shooting Note: For C44ID specific troubleshooting refer to the Dexen user manual supplied Table 9: Troubleshooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again.

  • Page 55: Parts Diagram

    Parts Diagram...

  • Page 56: Parts List

    Parts List Note: For C44ID specific replacement parts refer to the Dexen user manual supplied Table 10: C44I Parts List i r c l i P C44 Boarderview Surround Powder Coated (Gray) 50-3200 C44 Boarderview Surround Nickel Plated 50-3210 T . I...
  • Page 57 Notes...
  • Page 58 Notes...
  • Page 59 Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.
  • Page 60 _________________________________________ _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com Winter 2021 C-16243...
