Service guide | Disassembling and assembling PAH 10-12.5, PAHT 10-12.5 and PAHT G 10-12.5
Flange
Plugs
Front cover
Front
cover crews
Valve plate with
sealing
6
180R9095 | 521B0986 0 | DKCFN.PI.010.NA4.02| 06.2017
Housing with
swash plate
and bearing
Retainer plate
Pistons
Spring
Spring guide
Retainer guide
Cylinder barrel
Shaft seal
Port plate
