Service guide | Disassembling and assembling PAH 10-12.5, PAHT 10-12.5 and PAHT G 10-12.5

26. Wet the shaft seal and slide it over the

bush.

28. Press the shaft seal in position.

30. Mount the front cover and align it to the

screw holes.

180R9095 | 521B0986 0 | DKCFN.PI.010.NA4.02| 06.2017

27. Use the shaft seal tool when pressing the

shaft seal downwards.

29. Remove the bush.

31. Tighten the screws to a torque of 7 Nm.
