brel-motors MJE24S Quick Start Manual

Manual Brel 24mm electronic DC radio motor single shaft
Read the manual before you begin the installation. If these instructions are not followed,
this may lead to defects and injury in which there can be no claim on the warranty.
warning:
Children cannot recognize the dangers of electrical equipment and may therefore not work with it.
It is important to follow this instruction for your own safety.
1. Do not operate the motor in humid environments.
2. The motor must be installed correctly.
3. Keep the antenna in a good condition and do not shorten. The antenna should not come into contact with other metal parts
otherwise it will reduce the power.
4. The motor must be protected from direct moisture influences.
______________________________________________________________________________
Up
Channel - stop
Down
If you are using a multi-channel transmitter, you cannot program on the shared channel.
______________________________________________________________________________

Technical data of the motor

•
Motor Voltage:
•
Maximum ampère charger:
•
Power:
•
Torque:
•
Speed:
•
Ampèrage:
•
Moisture and dust:
•
Storage capacity is up to 20 channels
•
Working temperature of the motor:
o
Normal use:
o
Heavy use:
BREL motors is part of:
Type MJE24S
P2
Channel +
Type MJE24S
-10℃ tot +40℃
-20℃ tot +70℃
(mode en time have only one function
at a transmitter with a timer: DC458 en DC 920)
Mode
Time
DC 12V
1.0 A
6.8 Watt
0.6 Nm
34 rpm
0.57 A
IP40
Page 1
P1
