Unpacking Chassis Components

Step 4
Carefully move the chassis into place over the bolt holes. See the
on moving the chassis with the dolly.
Where side clearance is not enough to use the dolly, you must first lower the chassis to the floor and then slide
Note
it into place.
Step 5 Lock the dolly caster anti-rotation and brake systems.
Step 6 With a person on each side of the chassis, turn all four lifting cranks of the dolly counterclockwise slowly to lower the
chassis to the floor.
The dolly has four separate lifting cranks, each of which works independently when lifting or lowering the
Note
chassis. It is best to turn the lifting cranks simultaneously when lifting the chassis so as to not put undue stress
on the chassis frame or dolly and reduce the risk of tipping too far.
Step 7 Remove the dolly from the chassis.
Do not permanently locate the equipment on the dolly. Safely store the dolly after use. Statement
Warning
357
Step 8 Insert all anchor bolts.
Step 9 Tighten all bolts and nuts.
Unpacking Chassis Components
The remaining shipping boxes and pallets are now ready to be delivered from the receiving/shipping dock or
a site holding area to the final location of the Cisco NCS 6000 Series chassis.

Steps

Step 1
If possible, move the pallets to the same location as the unpacked and secured chassis. If not possible, move the individual
boxes containing the various components to the chassis location.
All components are packaged separately. Cards are attached and installed on a wooden board insert held in place
Note
by captive Phillips screws.
Step 2 Unpack all primary pallet parts from the packaging, and set the parts aside for installation.
Step 3 Unpack all secondary pallet parts from the packaging, and set the parts aside for installation.
Note Do not unpack individual cards until you are ready to install the cards in the chassis.
Step 4 Unpack all power components from the packaging, and set the parts carefully aside on an ESD-immune surface for
installation.
Step 5 Unpack all exterior cosmetic parts from the packaging and set the parts aside.
To continue with the installation of individual components, see the
Routers Hardware Installation Guide
Guide
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
42
or the Cisco Network Convergence 6000 Fabric Card Chassis Hardware Installation
Moving the Unpacked Chassis, on page 36
Cisco Network Convergence System 6000 Series
Securing the Chassis
for details
